White Rodgers 1F82-261 Installation And Operation Instructions Manual

Programmable electronic digital heat pump thermostat.
Hide thumbs


Operator: Save these instructions for future use!
Your new White-Rodgers 5-Day/1-Day/1-Day Digital Thermo-
stat uses the technology of a solid-state microcomputer to
provide precise time/temperature control. This thermostat offers
you the flexibility to design heating and cooling programs that fit
your needs.
• Separate 5-day (weekday) and 1-day/1-day (Saturday/Sunday)
programming with four separate time/temperature periods per day
• Simultaneous heat and cool program storage
• Preprogrammed temperature control
• Optional battery back-up for AC power loss
This thermostat is intended for use with a low voltage NEC
Class II system. Do not use this thermostat with a line voltage
system. If in doubt about whether your wiring is millivolt, line, or
low voltage, have it inspected by a qualified heating and air
conditioning contractor or electrician.
Do not exceed the specification ratings.
All wiring must conform to local and national electrical codes
and ordinances.
This control is a precision instrument, and should be handled
carefully. Rough handling or distorting components could cause
the control to malfunction.
To prevent electrical shock and/or equipment dam-
age, disconnect electric power to system at main fuse
or circuit breaker box until installation is complete.
Electrical Rating:
20 to 30 VAC 50/60 Hz. or D.C.
0.05 to 1.0 Amps (Load per terminal)
1.5 Amps Maximum Total Load (All terminals combined)
Setpoint Temperature Range:
45°F to 90°F (7°C to 32°C)
Operating Ambient Temperature Range:
32°F to 105°F
Operating Humidity Range:
0 to 90% RH (non-condensing)
Shipping Temperature Range:
-4°F to 149°F
ST. LOUIS, MISSOURI 63123-5398
Programmable Electronic Digital
Heat Pump Thermostat
• LCD continuously displays set point, and alternately dis-
plays time and room temperature
• Continuous Backlit display option
• Temperature override until next program period
• Manual program override (HOLD temperature)
• Temporary HOLD
• °F/°C convertibility
• Temperature range 45° to 90°F
• R, C, Y, W2, G, O/B, E, and L terminals for single or two-
transformer systems
Do not use on circuits exceeding specified voltage.
Higher voltage will damage control and could cause
shock or fire hazard.
Do not short out terminals on gas valve or primary
control to test. Short or incorrect wiring will damage
thermostat and could cause personal injury and/or
property damage.
Thermostat installation and all components of the
system shall conform to Class II (current limited)
circuits per the NEC code. Failure to do so could cause
a fire hazard.
For use with the following Class II systems:
• Standard heat pump systems with electric, gas or oil
Aux heat with 24VAC Hot and Common available
• Single-stage heat pump systems with no Aux heat with
24VAC Hot and Common available
• Millivolt systems
• Systems exceeding 30 VAC and 1.5 amps
• 3-wire zoned hydronic heating systems
Printed in U.S.A.
PART NO. 37-6175D
Replaces 37-6175C


   Related Manuals for White Rodgers 1F82-261

   Summary of Contents for White Rodgers 1F82-261

  • Page 1: Specifications

    -4°F to 149°F WHITE-RODGERS EMERSON ELECTRIC CO. 9797 REAVIS ROAD ST. LOUIS, MISSOURI 63123-5398 www.white-rodgers.com 1F82-261 Programmable Electronic Digital Heat Pump Thermostat INSTALLATION AND OPERATION INSTRUCTIONS • LCD continuously displays set point, and alternately dis- plays time and room temperature •...

  • Page 2: Remove Old Thermostat, Installation

    INSTALLATION REMOVE OLD THERMOSTAT 1. Shut off electricity at the main fuse box until installation is complete. Ensure that electrical power is disconnected. 2. Remove the front cover of the old thermostat. With wires still attached, remove wall plate from the wall. If the old thermostat has a wall mounting plate, remove the thermostat and the wall mounting plate as an assembly.

  • Page 3: Wiring Diagrams

    Changeover Relay* Compressor Contactor * Changeover Relay is energized in COOL when O/B switch is in the “O” position Changeover Relay is energized in HEAT when O/B switch is in the “B” position ** Jumper required to use a single Aux Heat for both Second Stage Heat and Emergency Figure 2.

  • Page 4: Check Thermostat Operation, The Thermostat Buttons And Switches

    CHECK THERMOSTAT OPERATION If at any time during testing your system does not operate properly, contact a qualified service person. Turn on power to the system. Fan Operation If your system does not have a G terminal connection, skip to Heating System.

  • Page 5: The Display, Configuration Menu

    The Display 9 Indicates day of the week. 10 Indicates a malfunction with the system. 11 Flame icon ( ) is displayed when the SYSTEM switch is in the HEAT position. Flame icon ( ) is displayed flashing when 2nd-stage heat (Aux or Emergency) is energized. Snowflake icon ( ) is displayed (non-flashing) when the SYSTEM switch is in the COOL position.

  • Page 6: Manual Operation, Programming Your Thermostat

    4) Select backlit display - The display backlight improves display contrast in low lighting conditions. Selecting back- light ON will keep the light on continuously. Selecting OFF will keep the light off. 5) Select Energy Management Recovery OFF or ON - Energy Management Recovery (EMR) causes the thermo- stat to start heating or cooling early to make the building temperature reach the program setpoint at the time you...

  • Page 7: Entering Program, Check Programming

    Use the table to plan your program time periods and the temperatures you want during each period. Fill in the complete table to have a record of your programs. Entering Your Program Set Current Time and Day 1. Press TIME button once. The display will show the hour only. EXAMPLE: 2.

  • Page 8: Troubleshooting

    TROUBLESHOOTING Reset Operation If a voltage spike or static discharge blanks out the display or causes erratic thermostat operation you can reset the thermo- Symptom No Heat/No Cool/No Fan (common problems) No Heat No Cool Heat, Cool or Fan Runs Constantly. Furnace Cycles Too Fast or Too Slow (narrow or wide temperature swing) Cooling Cycles Too Fast or Too Slow...
