- Page 4 3. SAFETY RULES – READ AND SAVE THESE INSTRUCTIONS Please observe the following general safety precautions carefully before and during all phases of handing, installation, removal, operation and maintenance of this appliance. 1. Read all instructions and safety information. Review assembly diagrams provided before installing your new ceiling fan.
- Page 5 4. JUNCTION BOX MOUNTING OPTIONS Your new ceiling fan will require a grounded electrical supply line of 220-240 volts AC, 50Hz circuit. The outlet box must be securely Outlet box anchored and capable of withstanding a load of at least 50 lbs (22.7 kgs). Figure 1 Figures 1,2 and 3 are examples of different ways to mount the outlet box.
-
Page 7: Make The Electric Connections
9. Now lift the motor assembly into position and place the hanger ball into the hanger bracket. Rotate down rod until the "Check Tab" has dropped into the "Registration Slot" and the down rod and ball assembly seat firmly. The down rod and ball assembly should not rotate if this is done correctly. -
Page 11: Troubleshooting
13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy.
