Measuring Functions

Measuring single distance

1 2
Aim active laser at target.

Permament measuring

1 2
2 sec
Aim active laser at target.

Add / Subtract

1 2
The next meas-
urement is added
7.332 m
to the previous
one.
3
1x 2x
3
The next meas-
urement is sub-
tracted from the
previous one.
geo-FENNEL EcoDist Pro
8.532 m
The last value mea-
sured is displayed.
8.532 m
5.515 m
12.847 m
®
Target surfaces: Measuring
errors can occur when meas-
uring to colourless liquids,
glass, styrofoam or semi-per-
meable surfaces or when
aiming at high gloss surfac-
es. Against dark surfaces the
measuring time increases.
3
Stops permanent measur-
ing.
The result is shown in the
main line and the measured
value above. This process
can be repeated as required.
The same process can be
used for adding or subtracting
areas or volumes.
EN
5
