- Page 1 DE | EN | FR Geo EasyTrack Auto Tracking System for Line Lasers USER MANUAL www.geo-fennel.de www.geo-fennel.com www.geo-fennel.fr...
- Page 2 Dear customer, Thank you for your confidence in us having purchased a geo-FENNEL instrument. This manual will help you to operate the instrument appropriately. Please read the manual carefully - particularly the safety instructions. A proper use only guarantees a longtime and reliable operation.
- Page 3 For line lasers with red and green beam · Compatible with all geo-FENNEL line lasers with pulse function for receier use. These are currently: CrossPointer5 SP , Geo5X-L360 HP , FL 66-Xtreme SP , FLG 64-GREEN HP , FLG 66-Xtreme GREEN, FL 69 HP , FL 1000 HP .
- Page 4 OPERATION KEYPAD OF THE EasyTRACK 1. ON/OFF LED 2. ON/OFF button tribrach Note: When the ON/OFF LED flashes the batteries must be replaced. RECEIVER 1. Circular bubble 2. Receiving window 3. Tube vial 4. Keypad 5. Receiving status indication 6. Side keypad 7 .
- Page 5 Power on the line laser and activate the reception mode · Position the line laser over the ground point · Press the POWER button (2) of the EasyTRACK (the LED will light red) · Power on the receiver (button 4) ·...
- Page 7 For this press the buttons RIGHT/LEFT after having powered on the receiver in order to direct the vertical line of the line laser to the required position. In order to save energy the EasyTRACK can be powered off when the tracking procedure has been completed.
- Page 8 SAFETY NOTES CARE AND CLEANING Handle measuring instruments with care. Clean with soft cloth only after any use. If necessary damp the cloth with some water. If the instrument is wet clean and dry it carefully. Pack it up only if it is per- fectly dry.
- Page 9 SAFETY INSTRUCTIONS · Follow up the instructions given in the user manual. · Do not stare into the beam. The laser beam can lead to eye injury. A direct look into the beam (even from greater distance) can cause damage to your eyes. ·...
- Page 10 GmbH Technische Änderungen vorbehalten. Kupferstraße 6 All instruments subject to technical changes. D-34225 Baunatal Sous réserve de modifications techniques. Tel. +49 561 / 49 21 45 +49 561 / 49 72 34 info@geo-fennel.de 10/2017 www.geo-fennel.de Precision by tradition.
