- Page 2 Thank you for purchasing the MFJ-1888 receive loop antenna. You new antenna is composed of High strength material for excellent rigidly and light weight. The MFJ-1888 is compact and excellent for restricted space or portable installations. The MFJ-1888 antenna frequency range extends above 30 MHz all the way down below the 500 KHz.
- Page 3 Use the two supplied U-Bolts to secure the loop to your mast as shown. Your mast should be no more than 1-3/4 in diameter and should be sturdy enough to support the MFJ-1888 antenna. Caution Do not use a grounding type antenna switch on the Antenna line from the Multicoupler to the Loop.
- Page 4 The Multicoupler can handle up to 4 receivers. Connect the receiver to one of the receive ports on the back. If using a transceiver with the MFJ-1888 make sure that you DO NOT transmit into the Multicoupler. If your radio has a receive only connector then connect the Multicoupler to that port.
- Page 5 Indoor Multicoupler...
- Page 6 NOTES...
- Page 7 MFJ Enterprises, Inc. at the time of warranty service. MFJ Enterprises, Inc. shall have the discretion to deny warranty without dated proof-of- purchase.
- Page 8 MFJ-1888 Manual 300 Industrial Park Road Version 0 Starkville, MS 39759 Printed In U.S.A.
