20 W LED Work Light
Art.no 18-2696
36-4846
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
If you have any questions regarding technical problems please contact our Customer Services.
Safety
• Read these instructions carefully before using the product.
• Never let children use the product without adult supervision.
• Never look directly into the light; it could damage your eyesight.
• Always unplug the light when it is not in use. Pull the plug, not the lead.
• Protect the work light from dust, water and extreme temperatures. High temperatures can damage the bulb.
• Before use, check that the plug, lead, diffuser and casing are all undamaged. If any damage is detected, do not
use the light until it has been repaired by a qualified technician.
• If the mains lead is damaged, to prevent any risk of fire or electrocution, it must only be replaced by
a qualified electrician.
• Never cover the work light. Never use the work light in the vicinity of explosive gases or liquids.
• The LED cannot be replaced.
• This product must not be dismantled or modified in any way.
• The light must only be used on the supplied stand, it must never be mounted on a wall or ceiling.
• Treat the light carefully.
• The light must only be connected to an earthed electrical socket.
• Before using the light, make sure that the supply voltage corresponds to the light's rated voltage.
Operation
1. Place the stand on a firm surface where it cannot tip over.
2. Adjust the tilt angle.
3. Plug the light into a wall socket.
Care and maintenance
• Never use strong cleaning agents/solvents to clean the product. Clean the light using a soft cloth.
• Always unplug the light before cleaning it.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local authority.
Specifications
Voltage
Input current
Power
Power factor
Light source
Lead
IP class
Class
Luminous flux
Beam angle
Tempered glass size 175 × 135 × 4 mm
GREAT BRITAIN • CUSTOMER SERVICE contact number: 08545 300 9799
e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Model S105A-P-20W-UK
S105A-P-20W
220–240 V AC, 50 Hz
0.105 A
20 W
0.9
1 LED. The light source is non-replaceable.
1.8 m rubber-clad cable H05RN-F 3 × 1 mm²
IP54
1
1300 lm
130°
