CO/Tech IPC30SA3A-E1UK Manual

30 W LED Tripod Work Light
Art.no 18-1403 Model IPC30SA3A-E1UK
36-7022 IPC30SA4A-E1
Please read the entire instruction manual before use and then save it for future
reference. We reserve the right for any errors in text or images and any necessary
changes made to technical data. In the event of technical problems or other
queries, please contact our Customer Services.

Safety

• This product is extremely bright. Do not look directly into the light, doing so
could cause eye damage.
• Never let children play with the product.
• The product must only be connected to an electrical socket with a 230 V
power supply.
• The product must not be used in rooms where explosive gases or liquids are
used or stored.
• Treat the product with care and do not subject it to shocks or impacts.
• Never immerse the product in water or other liquid.
• The product must not be covered.
• Never try to open the housing, repair or modify the product in any way.
• Never use the product if your hands are moist or wet.
• Never use the product if it, its mains lead or plug is damaged in any way.
• All repairs must be carried out by qualified service technicians using genuine
spare parts.
• The mains lead should be checked regularly. If the mains lead is damaged in
any way it must be replaced by a qualified electrician.
The light source of the light fitting must only be replaced by a qualified electrician.

Product description

1. [ l/0 ] On/off switch
2. 2 × 230 V power socket
3. Adjustment screws
(one on each side)
4. Fastening screw
Art.no: 36-7022
GREAT BRITAIN • CUSTOMER SERVICE tel 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
5. Height adjustment lock
6. Leg lock knob
7. Cable holder

Instructions for use

1. Open out the legs of the tripod and lock them in place by tightening the lock
knob (6).
2. Adjust the tripod to the desired height and tighten the adjustment locks (5).
3. Mount the work light onto the tripod and secure it using the fastening screw (4).
4. Connect the mains lead to a 230 V power point.
5. Undo the adjustment screws (3) and set the desired angle.
6. Switch the work light on using the power switch (1).
7. Switch off and unplug the work light after use.
1
2
3
4
Art.no: 18-1403

Power sockets (Art.no: 36-7022)

If any power tools are connected to the power sockets (2), the total combined
load must not exceed 2300 W.
The power switch next to the sockets only controls the work light, not the power
5
sockets.

Care and maintenance

•
6
•
7

Responsible disposal

This symbol indicates that this product should not be disposed
of with general household waste. This applies throughout
the entire EU. In order to prevent any harm to the environment
or health hazards caused by incorrect waste disposal,
the product must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
the product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.

Specifications

Rated voltage
Power
Power sockets
Colour
Light source
Colour temperature
Colour rendition
Beam angle
IP rating
Operating temperature
Mains cable
Work light size
Max tripod height

Important:

Switch the work light off and unplug it from the electrical outlet before wiping
it clean with a dry cloth.
Important: If the glass on the front of the work light is damaged, it must
be replaced before the light is used again. The work light must not be used if
the glass is damaged or missing.
220–240 V AC, 50/60 Hz
30 W
Max 2300 W combined total (Art.no: 36-7022)
Black
COB-LED, 2550 lm
4000 K
> 80 Ra
120°
IP44
−20 to 40 °C
2.8 m, H07RN-F 3G1.5 mm² (Art.no: 36-7022)
2.8 m, H05RN-F 3G1.0 mm² (Art.no: 18-1403)
17.5 × 14.5 × 13 cm
180 cm
