- Page 1 FlowControl Translation of the original manual...
-
Page 2: Table Of Contents
Table of contents Table of contents Table of revision ....................Safety ......................... Presentation of warning signs ......................Intended purpose of use ........................ General hazards ..........................State of technology......................... Personal protective equipment ....................... Spare parts and liability ........................General information ..................Purpose and use of the instructions .................... - Page 3 Table of contents Restart via keyboard ........................Operating lock via the keyboard ....................Viewing and resetting counting statistics ..................Setting the door control ........................5.10 Setting the LED Strips ........................5.11 Setting the Voice Box (Option) ....................... Servicing and maintenance ................General remarks ..........................
-
Page 4: Table Of Revision
Table of revision Table of revision Authorization levels New chapter ..............14 Count data analysis and data transfer (optional) New chapter ..............14 Select Permission Level New Chapter ............... 18 Setting the door control New chapter ..............20 Setting the LED Strips New funktion ............... -
Page 5: Safety
Safety Safety Presentation of warning signs Various symbols are used in this guide for easier understanding: NOTICE Useful advice and information to ensure correct and efficient workflow of the system. IMPORTANT Specific details which are essential for trouble-free operation of the sys- tem. -
Page 6: General Hazards
Safety General hazards The following section lists hazards that can be caused by the system even when used as intended. To reduce the risk of malfunction, damage to property or injury to persons and to avoid dangerous si- tuations, the safety instructions listed here must be observed. The specific safety instructions in the other sections of this manual must also be observed. - Page 7 Safety CAUTION Risk of material damage or injury due to unforeseen opening, closing or turning of the door! • The door can open, close or turn unexpectedly. This may result in damage to property or injury to persons. No persons may be present in the opening area of the system. ...
-
Page 8: State Of Technology
Safety DANGER Danger to life from electric current! • Contact with live parts may result in immediate danger to life due to electric shock. Damage to or removal of the insulation or individual components can be life-threatening. Before starting work on active parts of electrical systems and equipment, make sure that they are de-energised and secured for the duration of the work. -
Page 9: Personal Protective Equipment
Safety Personal protective equipment Personal protective equipment is used to protect persons from adverse effects on safety and health. Personnel must wear personal protective equipment during the various work activities on and with the system. Personal protective equipment is explained below: Hearing protection is used to protect the hearing from noise. -
Page 10: General Information
General information General information Purpose and use of the instructions These instructions are an integral part of the system and enable efficient and safe handling of the sys- tem. In order to ensure proper functioning, the instructions must be accessible at all times and kept in the immediate area of the system. -
Page 11: Target Groups
General information Target groups CAUTION Risk of injury if personnel are insufficiently qualified! If unqualified personnel work on the system or are in the danger zone of the sys- tem, dangers may arise which can cause serious injuries and considerable da- mage to property. -
Page 12: Description
Description Description Graphical presentation Sliding door Abbreviation Description Abbreviation Description Passage width Total height Overall view Example for 1-leaf sliding door Pos. Components Pos. Components Sensor bracket Sensor Control box LED-Strips Operating unit Speaker (optional) BAL_FlowControl_EN_1V2_REC_121-006454644 12/ 25... -
Page 13: Function
Description Function record FlowControl is an automatic people screening system for retail stores and shops. The system reliably counts all persons in both directions. If the pre-defined maximum number of people is reached or exceeded, the entrance door is automatically deactivated to prevent further intrusion of people. -
Page 14: Count Data Analysis And Data Transfer (Optional)
Description Engineer - Available settings ▪ Number of doors being monitored ▪ Sensor CAN bus addresses ▪ Sensor settings (Sensitivity, Sensor field boundaries, Object height, Sensor height) ▪ Language ▪ Show software version Count data analysis and data transfer (optional) Data-Box (optional) - Available settings ▪... -
Page 15: Technical Data
Yes (Actual and maximum number of persons is adjustable) On/Off button: Operating unit: BDE-D FC Interaction with sliding doors: Yes, all record doors plus third-party doors with radar sensors (relay contacts) Check compatibility with bus-connected radar sensors on third-party doors Mounting position LED strips: Exterior... - Page 16 Technical data VoiceBox (optional) Mains voltage: 12 - 24 V 10 W at 2 – 16 Ω Power rating sound module: Potential-free inputs (voice output): Speaker Output power: 25 W 4 – 8 Ω Speaker Intendance: Speaker volume: 86 dB Speaker frequency range: 90 –...
-
Page 17: Operation
Operation Operation BDE-D FC and key functions The electronic operating unit BDE-D FC is an input and output unit for the control and parameterization of the number of persons. The LCD display with background illumination provides information about the status with symbols and plain text. Messages are shown on the display as text information. -
Page 18: Instructional Symbols
Operation Instructional symbols NOTICE If an information or an error message occurs, the display of the set opera- ting mode remains active. A corresponding symbol is also displayed. It is also possible to display both symbols at the same time. Instructional symbol Type ▪... -
Page 19: Operating Lock Via The Keyboard
Operation Restart Hardware BDE-D FC Press key sequence Display icon Description ▪ Press the INFO 12 button for 12 se- Welcome conds. ▪ Restart of the hardware is performed. Operating lock via the keyboard Locking the control unit Press key sequence Display symbol Description ▪... -
Page 20: Setting The Door Control
Operation Reset counting statistics Path Selection Description ▪ The Total Count is reset. Statistics ▪ All entries in In-operation Count are → Reset cnt. reset. Setting the door control In the menu Parameter / Signalling the door control can be activated / deactivated when the person limit is reached. -
Page 21: Setting The Voice Box (Option)
Setting the volume of the voice output Rotary wheel on the sound card Description ▪ The volume of the voice output can be adjusted on the rotary wheel of the sound card. ▪ The sound card is located inside the FlowControl Box. BAL_FlowControl_EN_1V2_REC_121-006454644 21/ 25... -
Page 22: Servicing And Maintenance
Servicing and maintenance Servicing and maintenance General remarks According to the legal provision in force, the operating entity of the automatic door is responsible for its maintenance and for the user's safety, as soon as the installation has been handed over. The regular inspection of single elements by the operator requires little time investment and reinforces the prevention of accidents caused by an inappropriate use of the door. -
Page 23: Monthly Inspection Work To Be Carried Out By The Operating Company
Servicing and maintenance Monthly inspection work to be carried out by the operating company The monthly inspection and maintenance of individual components by the operator requires little time and serves the reliable function, increased service life and operational safety of the installation. Test / inspection Procedure Expected result... -
Page 24: Malfunctions
Taking out of service and disposal Malfunctions Behavior in event of faults In the event of an irregularity or malfunction, different displays are shown depending on the control unit connected. IMPORTANT If malfunctions that endanger the safety of individuals occur, the system must be turned off. -
Page 25: Taking Out Of Service And Disposal
All machine parts must be sorted by type of material and disposed of according to local regulations and guidelines. NOTICE The record door systems can be completely disassembled in reverse order. The automatic door mainly consists of the following materials: Aluminum: ▪... - Page 26 Great Britain www.recorduk.co.uk Magyarorszag www.record.hu Malaysia www.recorddoors.my Nederland www.recordbv.nl Österreich www.record.co.at Polska pl.record.global Schweiz www.record.ch Slovenija www.record.si Sverige www.record.se Türkiye tr.record.global United States www.recorddoors.com record global export www.record.global record Group www.record.group Subject to technical modifications Copyright © agtatec ag n° 121-006454644...
