- Page 1 FlowControl Translation of the original manual...
- Page 2 Document identification Article nr.: 121-006454644 Version: Publication date: 23/03/2021 Subject to technical modifications Copyright © agtatec ag...
-
Page 3: Table Of Contents
Table of contents Table of contents Table of revision ............................... 1 Safety................................. Presentation of warning signs....................... Intended purpose of use ........................General hazards ........................... State of technology ..........................Personal protective equipment ......................Spare parts and liability ........................2 General information ............................10 Purpose and use of the instructions ..................... -
Page 4: Table Of Revision
Table of revision Table of revision BDE-D FC Menu New chapter ................................ 20 4 / 28 BAL_FlowControl_EN_1V3_REC_121-006454644... -
Page 5: Safety
Safety Safety Presentation of warning signs Various symbols are used in this guide for easier understanding: NOTICE Useful advice and information to ensure correct and efficient workflow of the system. IMPORTANT Specific details which are essential for trouble-free operation of the system. IMPORTANT Important details which must be read for proper function of the system. -
Page 6: General Hazards
Safety General hazards The following section lists hazards that can be caused by the system even when used as intended. To reduce the risk of malfunction, damage to property or injury to persons and to avoid dangerous situations, the safety instructions listed here must be observed. The specific safety instructions in the other sections of this manual must also be observed. - Page 7 Safety CAUTION Risk of material damage or injury due to unforeseen opening, closing or turning of the door! a) The door can open, close or turn unexpectedly. This may result in damage to property or injury to persons. ð No persons may be present in the opening area of the system. ð...
-
Page 8: State Of Technology
Safety DANGER Danger to life due to electric current! a) In case of contact with live parts, there is an immediate danger to life due to electric shock. Damage to or removal of the insulation or individual components can be life-threatening. ð... -
Page 9: Spare Parts And Liability
Safety The head protection serves to protect against falling and flying parts and materials. It also protects the head from bumping into hard objects. Protective goggles protect the eyes from flying parts, dust, splinters or splashes. Protective gloves are designed to protect hands from friction, abrasions, punctures or serious injury and from burning caused by contacting hot surfaces. -
Page 10: General Information
General information General information Purpose and use of the instructions These instructions are an integral part of the system and enable efficient and safe handling of the sys- tem. In order to ensure proper functioning, the instructions must be accessible at all times and kept in the immediate area of the system. -
Page 11: General Definitions Of Terms
General information General definitions of terms The following terms are used in manuals for easier understanding: Term: Explanation: System System describes the door drive of the company Blasi GmbH, Carl- Benz-Str. 5-15, D - 77972 Mahlberg. Whenever instructions refer to a specific design, it will be specifically emphasized in the text. -
Page 12: Description
Description Description Graphical presentation Sliding door Abbreviation Description Abbreviation Description Passage width Total height Overall view Example for 1-leaf sliding door Pos. Components Pos. Components Sensor bracket Sensor Control box LED-Strips Operating unit Speaker (optional) 12 / 28 BAL_FlowControl_EN_1V3_REC_121-006454644... -
Page 13: Function
Description Function record FlowControl is an automatic people screening system for retail stores and shops. The system reliably counts all persons in both directions. If the pre-defined maximum number of people is reached or exceeded, the entrance door is automatically deactivated to prevent fur- ther intrusion of people. -
Page 14: Count Data Analysis And Data Transfer (Optional)
Description Engineer - Available settings – Number of doors being monitored – Sensor CAN bus addresses – Sensor settings (Sensitivity, Sensor field boundaries, Object height, Sensor height) – Language – Show software version Count data analysis and data transfer (optional) Data-Box (optional) - Available settings –... -
Page 15: Technical Data
Yes (Actual and maximum number of persons is ad- justable) On/Off button: Operating unit: BDE-D FC Interaction with sliding doors: Yes, all record doors plus third-party doors with radar sensors (relay contacts) Check compatibility with bus-connected radar sensors on third-party doors Mounting position LED strips: Exterior... - Page 16 Technical data VoiceBox (optional) Speaker Intendance: 4 – 8 Ω Speaker volume: 86 dB Speaker frequency range: 90 – 17 000 Hz Environmental conditions Temperature range: -15°C to +50°C Moisture range: up to 85% rel. humidity, non-condensing Protection class: LED Strips IP65 Miscellaneous IP44 16 / 28 BAL_FlowControl_EN_1V3_REC_121-006454644...
-
Page 17: Operation
Operation Operation BDE-D FC and key functions The electronic operating unit BDE-D FC is an input and output unit for the con- trol and parameterization of the number of persons. The LCD display with background illumination provides information about the status with symbols and plain text. -
Page 18: Instructional Symbols
Operation Instructional symbols NOTICE If an information or an error message occurs, the display of the set operating mode remains active. A corresponding symbol is also displayed. It is also possible to display both symbols at the same time. Instructional symbol Type –... -
Page 19: Operating Lock Via The Keyboard
Operation Restart Hardware BDE-D FC Press key sequence Display icon Description – Press the INFO 12 button for 12 seconds. Welcome – Restart of the hardware is performed. Operating lock via the keyboard Locking the control unit Press key sequence Display symbol Description –... -
Page 20: Bde-D Fc Menu
Operation BDE-D FC Menu BDE-D FC Menu Menu item Default Description Select the Manager authorisation level Parameters > Counting Press key sequence (double-click) Max. no people Setting the maximum number of persons allowed Parameters > Signalisation Door control ON = door is automatically deactivated when the person limit is reached From Software version 2.3.0 LED output... -
Page 21: Viewing And Resetting Counting Statistics
Operation Viewing and resetting counting statistics NOTICE Switching with the ON / OFF key , creates a new entry in the system (In-operation Count). A maximum of 15 entries are possible, after which a new entry replaces the oldest counter value. -
Page 22: Setting The Led Strips
Operation 5.11 Setting the LED Strips signalisation The flashing of the LED strips can be activated and adjusted in the Parameter / Signalisation menu. The blinking occurs when the LED blinking counter reaches the set limit. blink duration blink interval Activate / deactivate door control Path Selection... -
Page 23: Setting The Voice Box (Option)
Operation 5.12 Setting the Voice Box (Option) signalisation In the menu Parameter / Signalisation the voice output can be ac- tivated / deactivated and adjusted. voice output When the set personal limit is reached, a voice message is out- put. repeat delay Example:„Please wait here“... -
Page 24: Servicing And Maintenance
Servicing and maintenance Servicing and maintenance General remarks According to the legal provision in force, the operating entity of the automatic door is responsible for its maintenance and for the user's safety, as soon as the installation has been handed over. The regular inspection of single elements by the operator requires little time investment and rein- forces the prevention of accidents caused by an inappropriate use of the door. -
Page 25: Monthly Inspection Work To Be Carried Out By The Operating Company
Servicing and maintenance Monthly inspection work to be carried out by the operating company The monthly inspection and maintenance of individual components by the operator requires little time and serves the reliable function, increased service life and operational safety of the installation. Test / inspection Procedure Expected result... -
Page 26: Malfunctions
Malfunctions Malfunctions Behavior in event of faults In the event of an irregularity or malfunction, different displays are shown depending on the control unit connected. IMPORTANT If malfunctions that endanger the safety of individuals occur, the system must be turned off. It may not be turned back on until the problem has been resolved by a professional and the danger no long exists. -
Page 27: Taking Out Of Service And Disposal
Taking out of service and disposal Taking out of service and disposal Decommissioning When shutting down or taking out of service, the system is disconnected from the mains supply and any existing battery is unplugged. NOTICE After each temporary shutdown a new commissioning must be carried out. Dismantling and disposal IMPORTANT All machine parts must be sorted by type of material and disposed of according to... - Page 28 Denmark www.record-danmark.dk España www.record.es France www.record.fr Great Britain www.recorduk.co.uk Malaysia www.recorddoors.my Polska pl.record.global Schweiz www.record.ch Sverige www.record.se Türkiye tr.record.global United States www.recorddoors.com record global export www.record.global record Group www.record.group Subject to technical modifications Copyright © agtatec ag No. 121-006454644...
