THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center.
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6X20 Combination Bolt 36+1 M6X50 Combination Bolt 12+1 Hex Wrench ARM CHAIR PACKAGE CONTENTS Part Description Quantity Arm Chair Right Arm Arm Chair Left Arm Arm Chair Seat Arm Chair Back Arm Chair Seat Cushion Arm Chair Lumbar...
Pre-assembly (continued) ARMLESS CHAIR PACKAGE CONTENTS Part Description Quantity Armless Chair Back Left Side Panel Right Side Panel Armless Chair Seat Armless Chair Seat Cushion Armless Chair Lumbar HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
Arm Chair Assembly Attaching The Arm Chair Seat To The Arm Chair Left Arm Attach the arm chair seat (C) to the arm chair left arm (B) using M6X20 combination bolts (AA), Do not tighten the bolts at this step. NOTE: Loosley tighten all the bolts using hex wrench (CC).
Page 7
Arm Chair Assembly (continued) Attaching The Arm Chair Right Arm To The Arm Chair Seat And Back Attach the arm chair right arm (A) to the arm chair seat (C) using M6X20 combination bolts (AA). Attach the arm chair right arm (A) to the arm chair back (D) using M6X20 combination bolt (AA). Do not tighten the bolts at this step.
Page 8
Arm Chair Assembly (continued) Tightening The Bolts Once all of the bolts are in place, fully tighten the bolts using the hex wrench (CC). Place the arm chair seat cushion (E) and the arm chair lumbar (F) to finish the assembly of the arm chair. Ensure all connections are secure before use.
Armless Chair Assembly Attaching The Armless Chair Seat To The Armless Chair Back Attach the armless chair seat (J) to the armless chair back (G) using M6X50 combination bolts (BB), Do not tighten the bolts at this step. NOTE: Loosley tighten all the bolts using hex wrench (CC). Attaching The Side Panels To The Armless Chair Seat And Back Attach the left side panel (H) to the armless chair seat (J) using an M6x20 combination bolt (AA).
Armless Chair Assembly (continued) Tightening The Bolts Once all of the bolts are in place, fully tighten the bolts using the hex wrench (CC). Turn the armless chair right side up. Place the armless chair seat cushion (K) and the armless chair lumbar (L) to finish the assembly of the chair. Ensure all connections are secure before use.
Page 11
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
