Model # FRS80961-ST
USE AND CARE GUIDE
HAYMONT STEEL WICKER 7PC DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY HAYMONT FRS80961-ST
Summary of Contents for HAMPTON BAY HAYMONT FRS80961-ST
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty YEAR FRAME AND YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M8x20 Combination Hex Bolt M6x15 Combination Bolt 16+1 Hand Knob 12+1 Hex Wrench Wrench STATIONARY CHAIR PACKAGE CONTENTS Part Description Quantity Chair Bucket Chair Base Seat Cushion... -
Page 5: Swivel Chair Package Contents
Pre-Assembly (continued) SWIVEL CHAIR PACKAGE CONTENTS Part Description Quantity Seat Cushion Swivel Chair Bucket Support Tube Swivel Base TABLE PACKAGE CONTENTS Part Description Quantity Table Top Table Leg Support Bar Umbrella Ring HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. -
Page 6: Stationary Chair Assembly
Stationary Chair Assembly Attaching The Chair Base To The Chair Bucket Place the chair bucket (A) upside down on a soft surface. Attach the chair base (B) to the chair bucket (A) using hand knobs (CC). NOTE: Loosely tighten all the bolts using the hex wrench (DD). Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (DD). -
Page 7: Swivel Chair Assembly
Swivel Chair Assembly Attaching The Support Tube To The Swivel Chair Bucket Place the swivel chair bucket (D) upside down on a soft surface. Attach the support tube (E) to the swivel chair bucket (D) using M8x20 combination hex bolts (AA). NOTE: Loosely tighten all the bolts using the wrench (EE). - Page 8 Table Assembly Connecting The Table Leg To The Table Top Place the table top (G) upside down on a soft surface. Attach the table legs (H) to the table top (G) using M6x15 combination bolts (BB). NOTE: Loosely tighten all the bolts using the hex wrench (DD). Connecting The Support Bar To The Table Legs Connect the support bar (I) to the table legs (H) using M6x15 combination bolts (BB).
-
Page 9: Care And Cleaning
Table Assembly (continued) Tightening The Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (DD). Turn the table right side up and put the umbrella ring (J) on the table top (G). Ensure all connections are secure before use. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
