8
Connecting USB Peripherals
1.
USB Peripherals: Plug the USB device cable into the USB IN port.
2.
Networking and modem cables: Plug the router cable into the LAN IN port.
3.
Microphone: Plug the microphone cable into the MIC port.
USB equipment
USB cable
Network cable
audio cable
9
HDMI Connections
HDMI IN
HDMI cable
10
General Setting
Input sources, Volume, Back light, and Flicker free
Router and other
network signal output
Network cable
11
More OSD settings
Audio Setting
Display Setting
Item
Description
Click to launch annotation app
Click to show wireless screen sharing app
Click to switch to Slot-in PC source
Screen Setting
Adjust Setting
Item
Description
Click to open web browser
Click to open cloud meeting
Click to pop up app list
