Remote Control Overview

Press to turn the display
Press to scroll down
ON/OFF
Enter button. Press it to
Mute / Unmute select options.
Display information of the Writing software startup
current input source
Shortcut button to exit
Blank screen
dialog boxes
FREEZE
Freeze screen
Back
Numeric input button
PC 'Space' button
Press to switch between
CH+ : PC previous page
PC applications
CH- : PC next page
Numeric input button
Increase / Decrease volume
F1:
Close current PC window Windows F1 Function
F2:
Windows F2 Function
Source selection button
F3:
Windows F3 Function
Press to display Menu
F4:
Windows F4 Function
Screen capture
F5:
Windows F5 Function
PC 'Tab' button
F6:
Windows F6 Function
Switch to slot in PC desktop
F7:
Windows F7 Function
PC 'Backspace' button
F8:
Windows F8 Function
PC 'Windows' button
F9:
PC 'Menu' button Windows F9 Function
F10:
Windows F10 Function
Press to scroll up
F11:
Windows F11 Function
Press to scroll left
F12:
Windows F12 Function
Press to scroll right
6

Connecting an External PC

1. To display video and sound from an external PC follow the instructions below:
Note: External PCs can also be connected to the display via HDMI cable.
• Connect a VGA cable (15-pin) from your external PC to the VGA IN port on the
display.
• Connect an audio cable from the AUDIO OUT port on your external PC to the
AUDIO IN port on the display.
2.
Connect a USB cable to the external PC from the TOUCH OUT port of the display.
Note: For optimal results, select 1920x1080p as the external computer's input
resolution.
TOUCH 2
AUDIO IN VGA TOUCH2
7
RS232 Connections
When you use an RS232 serial port cable to connect your display
to an external computer, certain functions can be controlled by the
PC, including power on/off, volume adjustment and more.
Serial Port Cable
Computer
