1364
12" Abrasive Cutoff Machine
1365
14" Abrasive Cutoff Machine
1210
Utility Die Grinder
162
Boschtools.com
Cu tof f M a ch i n e & U ti l i ty D ie
Features
• 15.0 Amps, 5,000 RPM
• Natural debris removal - Wheel rotation carries
sparks, dust and debris away from the operator
• AC/DC capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Reinforced armature windings - Protects motor
against abrasive dust and metal debris
• Service Minder™ Brushes - Eliminate guesswork,
stops the tool when preventative maintenance
is required
• Reversible handle - Wraparound side handle
mounts left or right for added convenience
and versatility
• Large footplate - Improves stability and allows
greater depth of cut, smooth on both sides
for guiding
• Reversible fire position - Tool comes set up in fire
forward position, but is easily changed to fire
reverse position without additional accessories
Features
• 15 Amps, 4,300 RPM
• Natural debris removal - Wheel rotation carries
sparks, dust and debris away from the operator
• AC/DC capability - Extends the versatility of the
tool by working from DC outlets such as welders
and generators
• Reinforced armature windings - Protects motor
against abrasive dust and metal debris
• Service Minder™ Brushes - Eliminate guesswork,
stops the tool when preventative maintenance
is required
• Reversible handle - Wrap around side handle
mounts left or right for added convenience
and versatility
• Large footplate - Improves stability and allows
greater depth of cut, smooth on both sides
for guiding
• Reversible fire position - Tool comes set up in fire
forward position, but is easily changed to fire
reverse position without additional accessories
Features
• 4.6 Amps, 27,000 RPM
• Lock-on/off switch - For extended use applications
• 43 mm flange diameter
Toll Free: 877-BOSCH-99
Gr i n de r
Specifications
Rating
Amperage
Max. Motor HP
No Load RPM
Wheel Diameter
Depth of Cut
Spindle Thread
Length (in.)
Weight (lbs.)
Includes
Wrap Around Side Handle ... 1 607 000 247
Wheel Guard .......................... 2 605 510 133
Adjustable Footplate ............ 2 608 190 025
Inside Flange .......................... 1 605 703 067
7/8" Arbor Locking Nut ......... 2 610 917 054
1" Arbor Locking Nut ............. 1 603 340 011
3/8" Allen Wrench .................. 1 607 950 038
Outside Flange ...................... 1 605 703 068
Replacement Equipment
6mm Allen Wrench ................ 1 907 950 007
See page 171 for
BOSCH
grinder accessories.
Specifications
Rating
Amperage
Max. Motor HP
No Load RPM
Wheel Diameter
Depth of Cut
Spindle Thread
Length (in.)
Weight (lbs.)
Includes
Auxiliary Handle ..................... 1 607 000 247
Wheel Guard .......................... 2 605 510 132
Adjustable Footplate ............ 2 608 190 025
Inside Flange .......................... 1 605 703 078
7/8" Arbor Locking Nut ......... 2 610 917 054
1" Arbor Locking Nut ............. 1 603 340 011
3/8" Allen Wrench .................. 1 607 950 038
Outside Flange ...................... 1 605 703 077
Replacement Equipment
6mm Allen Wrench ................ 1 907 950 007
See page 171 for
BOSCH
grinder accessories.
Specifications
Rating
Amperage
No Load RPM
Collet Capacity
Mounted Point
Polishing Wheel
Length (in.)
Weight (lbs.)
Includes
1/4" Collect ............................ 2 608 570 048
Wrench .................................... 1 607 950 525
Shaft Lock Pin ........................ 2 603 101 035
See page 175 for
BOSCH
grinder accessories.
120V AC/DC
15.0
4.7
5,000
12"
3-7/8"
5/8"-11
24-1/2"
24-1/2
120 V AC/DC
15.0
4.7
4300
14"
4-7/8"
5/8"-11
24-1/2"
27
120V AC
4.6
27,000
1/8"-1/4"
Up to 1" Dia.
Up to 2" Dia.
9.4"
3.25
