Maintenance; Extension Cords - Bosch ROTOZIP RZ18V Operating/Safety Instructions Manual

RZ 2610925600 9-05 9/1/05
Service
NO USER SERVICEABLE
WARNING
!
PARTS INSIDE. Preventive
maintenance performed by unauthorized
personnel may result in misplacing of
internal wires and components which
could cause serious hazard. We recom-
mend that all tool service be performed by a
Bosch Factory Service Center or Authorized
Bosch Service Station. SERVICEMEN:
Disconnect tool and/or charger from power
source before servicing.
BATTERIES
Be alert for battery packs that are nearing
their end of life. If you notice decreased
tool performance or significantly shorter
running time between charges then it is time
to replace the battery pack. Failure to do so
can cause the tool to operate improperly or
damage the charger.
Long term battery storage should be in
the discharged state. Battery packs last
longer and re-charge better when they are
stored discharged. Remember to fully re-
charge battery packs before using after
prolonged storage.
TOOL LUBRICATION
Your Bosch tool has been properly lubricated
and is ready for use.
CHUCK LUBRICATION
The wrenchless chuck has been properly
lubricated and is ready to use. If the chuck's
jaws begin to stick during use, the chuck
requires lubrication. To lubricate the chuck,
first remove debris from the inside of the
chuck with compressed air. Apply a pea-
If an extension cord is
WARNING
!
necessary, a cord with
adequate size conductors that is capable
of carrying the current necessary for your
tool must be used. This will prevent
excessive voltage drop, loss of power or
overheating. Grounded tools must use 3-
wire extension cords that have 3-prong plugs
and receptacles.
NOTE: The smaller the gauge number, the
heavier the cord.
11:04 AM Page 20

Maintenance

sized amount of general-purpose grease to
the sides of the jaws, and adjust the chuck
through its full range of motion to distribute
the grease.
The motor in your tool has been engineered
for many hours of dependable service. To
maintain peak efficiency of the motor, we
recommend it be examined every six
months. Only a genuine Bosch replacement
motor specially designed for your tool should
be used.
Bearings which become noisy (due to heavy
load or very abrasive material cutting) should
be replaced at once to avoid overheating and
motor failure.
WARNING
!
charger from the power supply before
cleaning. The tool may be cleaned most
effectively with compressed dry air. Always
wear safety goggles when cleaning tools
with compressed air.
Ventilation openings and switch levers must be
kept clean and free of foreign matter. Do not
attempt to clean by inserting pointed objects
through opening.
CAUTION
!
parts. Some of these are: gasoline, carbon
tetrachloride, chlorinated cleaning solvents,
ammonia and household detergents that
contain ammonia.

Extension Cords

RECOMMENDED SIZES OF EXTENSION CORDS
120 VOLT ALTERNATING CURRENT TOOLS
Tool's
Ampere
Rating
3-6
6-8
8-10
10-12
12-16
-20-
D.C. MOTORS
BEARINGS
Cleaning
To avoid accidents, always
disconnect the tool and/or
Certain cleaning agents and
solvents damage plastic
Cord Size in A.W.G. Wire Sizes in mm
Cord Length in Feet Cord Length in Meters
25 50 100 150 15 30
18 16 16 14 0.75 0.75 1.5
18 16 14 12 0.75 1.0 2.5
18 16 14 12 0.75 1.0 2.5
16 16 14 12 1.0 2.5 4.0
14 12 — — — —
2
60 120
2.5
4.0
4.0
—
— —
