Functional Description and Specifications
Zipmate attachment must be used only with an hard auxiliary control
WARNING
!
side handle. Two handed control of solid gripping handles will provide
sufficient control of the cutting wheel in case of recoil.
Disconnect battery pack from tool or place the switch in the locked or
WARNING
!
off position before making any assembly, adjustments or changing
accessories. Such preventive safety measures reduce the risk of starting the tool
accidentally.
FIG. 1
LOCK LEVER
ADJUSTMENT
SCREW
Recommended for use with: Rebel, Revolution,
Hard auxiliary control handle must be obtained for models RZ1 and RZ25.
WARNING
!
Call 1-877-ROTOZIP.
Note : The speed of your tool will be reduced 2 : 1 when using your Abrasive Cut-Off attachment.
Always
WARNING
!
handle
control over torque reaction or kick-back.
Operation of the tool without the auxiliary
handle could cause loss of control of the tool,
resulting in possible serious personal injury.
REMOVING AND INSTALLING
ABRASIVE CUT OFF ATTACHMENT
Disconnect battery pack
WARNING
!
from tool or place the
switch in the locked or off position before
making any assembly, adjustments or
changing accessories. Such preventive
safety measures reduce the risk of starting
the tool accidentally. Make certain that the
collet nut is securely tightened before turning
the tool on.
11:04 AM Page 17
®
Zipmate Abrasive Cut Off Attachment
WHEEL GUARD
LOCK LEVER
LOCK
LEVER
and all RZ model Spiral Saws.
Assembly
use auxiliary
for maximum
-17-
WHEEL GUARD
LOCK LEVER
ADJUSTMENT
SHAFT LOCK
1. Insert the 1/4" collet into the collet nut.
Loosely thread the collet nut onto the output
shaft (Fig. 2).
2. Insert drive bit into the collet until it stops,
and securely tighten the collet nut with the
wrench.
3. Open locking lever
attachment onto the collar. Note: It may be
necessary to rotate attachment slightly and
hold both the tool and attachment shaft
locks to engage square end of drive bit into
attachment.
4. Position attachment as shown and lock the
clamp lever.
Use the allen wrench to adjust the lock lever
adjustment screw.
GUARD
SCREW
ABRASIVE
WHEEL
and position
