- Page 1 M Series Operating Instructions Hand Pallet Truck Eoslift Automation Technology Corp. No.99 Yanjia Road, Yuantong Town, Haiyan, Zhejiang Province China 314317 Tel：+86 573 8622 9999 Fax: +86 573 8622 2900 info@eoslift.com www.eoslift.com...
- Page 2 M Series Hand Pallet Trucks Esteemed users: For proper and safe operation of the products, before using the products, be sure to read the operating instructions carefully and retain them properly for future reference. The operator need to have proficient operation skills.
- Page 3 M Series Hand Pallet Trucks Table of contents Ⅰ．Technical parameters Ⅱ. Safety rules Ⅲ．Installation of handles Ⅳ．Adjusting the finger grip handle Ⅴ．Maintenance Ⅵ．Transportion, loading, test and storage Ⅶ．Troubles shooting Ⅷ．Parts list...
- Page 4 M Series Hand Pallet Trucks Technical parameters Model M20/M25/M30/M20Q/M25Q/M30Q/M20Z/M25Z/M30Z Rated capacity 2000/2500/3000 Load center Service weight 72-79 Wheel PU/NYLON/RUBBER Max. lift height 200 Min. fork height Steer wheel Φ200x50/Φ180x50 Φ180x50 Load wheel Φ80x70 Φ74x70 Single Load wheel Φ74x93 Fork width...
- Page 5 M Series Hand Pallet Trucks Safety rules Installation of handles The truck is only applicable to indoor use and the application environment must meet the following conditions: Free from rainwater or corrosion of harmful gases; Room temperature of -20°C~+40°C; Relative ambient humidity <90%;...
- Page 6 M Series Hand Pallet Trucks Adjusting the finger grip handle Maintenance On the handle of this pallet truck, you can find finger grip control handle(1-1) which can be regulated in 1 The truck should be parked with the forks lowered to min. height.
- Page 7 M Series Hand Pallet Trucks Troubles shooting Transportion, loading, test and storage This chapter enables the user to identify and rectifies basic faults and the effects of incorrect operation. When trying to locate a fault, proceed in the order shown in the table below. If, after carrying out the following remedial action listed in “actions”, the truck cannot be restored to operation, contact the...
- Page 8 M Series Hand Pallet Trucks Parts list · Frame Troubles shooting Description Qty. Parts number WC02000001 Frame(2.5t, 540×1150-85), 5012 Impurities in the oil cause Change hydraulic oil the valve to be unable to WC02000083 Frame(3.0t, 540×1150-85), 5012 close tightly WC02000079 Frame(2.5t, 685×1220-85), 5012...
- Page 9 M Series Hand Pallet Trucks Parts list · Frame Description Qty. Description Qty. Parts number Parts number WC02000605 Push rod welded (1150), galvanized WC02000160 Iron-core PU wheel φ74 × 70, bright red PU, black iron core WC02000182 Push rod welded (1220), galvanized WC02000120 Nylon wheel φ74 ×...
- Page 10 M Series Hand Pallet Trucks Parts list · Frame Description Qty. Parts number WC02000688 Small wheel carrier (75), black WC02000185 Small wheel carrier (85), galvanized WC02000894 Small wheel carrier (75), galvanized WE06000001 GB879.1, Spring type straight pin 5×32, blackening WC02000022...
- Page 11 M Series Hand Pallet Trucks Parts list · Handle Description Qty. Parts number WJ10800014 Handle welded WJ10800015 Clamping roller WJ10800016 Roller pin WJ10800011 Finger grip handle WJ10800006 Spring type pin (5) WJ10800003 Spring type pin (6) WJ10800004 Spring type pin (7)
- Page 12 M Series Hand Pallet Trucks Parts list · Cylinder Description Qty. Parts number Valve body welded(75), galvanized WC02000157 WC02000033 Valve body welded(85), galvanized WC02000060 GB982, Combination sealing gasket 10 Screw WC02000036 WC02000061 Seal ring UHS35 WC02000059 GB3452.1, O-ringφ34.5×3.55 WC02000058 Dustproof ring DH35...
- Page 13 M Series Hand Pallet Trucks Parts list · Integrated valve Description Qty. Parts number WC02000051 Push pin sleeve WC02000065 GB3452.1, O-ringφ15.2×2.4 WC02000067 GB3452.1, O-ringφ8×1.8 WC02000053 Return valve sleeve WC02000066 GB3452.1, O-ringφ9.5×1.8 WC02000050 Stem WC02000052 Unloading spring WC02000054 O-ring retainer Ⅱ...
- Page 14 M Series Hand Pallet Trucks Parts list · Quick lift cylinder Description Qty. Parts number WC02000121 Valve bodyseaming part(AC-85), quick lift pump, galvanized WC02000723 Valve bodyseaming part(AC-75), with quick lift, galvanized WC02000060 GB982, Seal washer 10 WC02000036 Bolt WC02000061 Seal ring UHS35 WC02000059 GB3452.1, O-ringφ34.5×3.55...
