Programming
CHANNEL NAME can be changed by using the Scroll "UP" key until you reach "CHANNEL NAME".
Use the UP/DOWN scroll keys to change each letter. Press "OK" to confirm channel name change.
LCN (Logic Channel Number) can be moved from its default position (101, 102) to a different channel
number (e.g. 4, 5) by scrolling UP/DOWN in the LCN option for each channel. Once selected, press
the "OK" button to lock your channel change.
NOTE: Repeat this process for each Input of your digi-MOD HD Modulator.
Video Output – digi-MOD HD can distribute either MPEG-2 or AVC (MPEG-4) signals to suit your
installation requirement. Via the "VIDEO OUTPUT" option in the menu, simply select the Video Output
per input to either MPEG-2 or AVC (MPEG-4) and press OK (allow 10 seconds for change to apply).
Video Input – allows you to select which VIDEO INPUT on the HD1000DM / HD2000DM you wish to
modulate (HDMI, COMPONENT, COMPOSITE). There is also an "AUTO" (default) option in the setting
that will automatically display the highest resolution available.
Audio Input – allows you to select which audio input on the HD1000DM / HD2000DM you wish to
modulate (OPTICAL, COAXIAL, ANALOGUE).
Audio Output - allows you to select which audio format on the HD1000DM / HD2000DM you wish to
modulate into your system (AC3, AAC, MP2).

IMPORTANT NOTE:

• You must re-scan the TV once setting has been changed or the TV may not display
the picture and sound correctly.
• Once programming is complete it is recommended that the system be reset by
pressing the reset button
Installing Multiple digi-MOD HD's in an installation
Please ensure each digi-MOD HD has different settings in the categories below if you are installing 2
or more in an installation.
• OUTPUT CHANNEL
• STREAM ID
• CHANNEL NAME
• LCN
• PROGRAM NUMBER
IMPORTANT NOTE:
• Failure to change the above settings will result in conflict and will not install all
channels correctly.
on the face of the module.
