Hardware Connection

1. Connect the relevant Video Output from the video source (eg: Cable TV, Pay TV, DVD, VCR, Camera) to
the relevant Video Input connector E
2. Connect the relevant Audio Output cable from the audio source to the relevant Audio Input
required) on the rear of the HD-1000DM / HD-2000DM Modulator.
3. Connect the RF Output K from the HD-1000DM / HD-2000DM to the Modulator Input on the RF
Distribution Module RL-RF380. Alternatively connect the RF Output
directly to a television set.
4. Connect the supplied IEC Power Cable to the Power Socket.
5. Repeat steps 1-2 for connection of other sources to AV Input IN2 for HD-2000DM
NOTE: If using HDMI, there is no need to connect an additional Audio Cable.

Initial Startup

1. Power Up the digi-MOD HD
2. Wait until digi-MOD HD reads "Running" then enter the menu by selecting the "OK" button
3. Enter Password "0000" and press "OK"
4. The LCD screen will now display "ADVANCED MENU OUTPUT CHANNEL" - select the "OK" button
5. The LCD screen will now display "OUTPUT CHANNEL 21" with the frequency in MHz. In some TV sets
Channel 21 is not available, so it is recommended to change this to appropriate available channel to suit your
installation (40, 50, 60 etc.) Once you have selected a channel number, Select "OK" to lock in the change.
6. Once Output Channel has been changed, wait up to 20 seconds for picture to appear.
7. Change any other settings via the "MENU" as required (refer to Technical Specifications)
8. Once finished programming use the "UP" scroll button until the LCD display reads "ADVANCED MENU
EXIT", select "OK"
9. The LCD will now read "EXIT, EXIT MENU". Select "OK". The LCD display will now show "Running"
10. Auto Scan for Channels on the TV set with the digi-MOD HD connected and powered.
11. Sources for selected digi-MOD HD Channel selection, (e.g channel 40), are found on TV channels 101
(adjustable - refer to Programming LCN)
NOTE: If the digi-MOD HD is powered down, there is no need to reconfigure. All settings will remain
unless a factory default is done.
- on the rear of the HD-1000DM / HD-2000DM Modulator.
G
to an existing distribution system or
K
L .
Programming
CHANNEL NAME can be changed by using the Scroll "UP" key until you reach "CHANNEL NAME". Use
the UP/DOWN scroll keys to change each letter. Click "OK" to confirm channel name change.
H
- (if
J
LCN (Logic Channel Number) can be moved from its default position (101, 102) to a different channel
number (e.g. 4, 5) by scrolling UP/DOWN in the LCN option for each channel. Once selected, press the
"OK" button to lock your channel change.
NOTE: Repeat this process for each Input of your digi-MOD HD Modulator.
Video Output – digi-MOD HD can distribute either MPEG-2 or AVC (MPEG-4) signals to suit your instal-
lation requirement. Via the "VIDEO OUTPUT" option in the menu, simply select the Video Output per
input to either MPEG-2 or AVC (MPEG-4) and press OK (allow 10 seconds for change to apply).
Video Input – allows you to select which VIDEO INPUT on the HD1000DM / HD2000DM you wish to
modulate (HDMI, COMPONENT, COMPOSITE). There is also an "AUTO" (default) option in the setting
that will automatically display the highest resolution available.
Audio Input – allows you to select which audio input on the HD1000DM / HD2000DM you wish to
modulate (OPTICAL, COAXIAL, ANALOG).
Audio Output - allows you to select which audio format on the HD1000DM / HD2000DM you wish to
modulate into your system (AC3, AAC, MP2).

IMPORTANT NOTE:

• You must re-scan the TV once setting has been changed or the TV may not display the
picture and sound correctly.
• Once programming complete it is recommended that the system be reset by pressing the
reset button A on the face of the module.
Installing multiple digi-MOD HD's in an installation
Please ensure each digi-MOD HD has different settings in the categories below if you are installing 2 or
more in an installation.
OUTPUT CHANNEL
STREAM ID
CHANNEL NAME
LCN
IMPORTANT NOTE: Failure to change the above settings will result in conflict and will not
install all channels correctly.
