Technical Specifications

INPUT
Input Connectors
Video Input level
Audio Input
Audio Input Level
Input Impedance
OUTPUT
Frequency Range
Output Level
Output Impedance
Channel Bandwidth
Channel Level Adjustment
MER
MODULATION
Video Resolution
Video Compression
Audio Compression
LCN
Carrier (OFDM Mode)
Guard Intervals
Code Rate (FEC)
Constellations
GENERAL
Power Supply
Consumption
Languages
Dimentions
Weight
RL-HD1000DM
HDMI Input (Video + Audio)
Y, Pb, Pr Component Input (Video)
Composite Input (Video)
L/R Channel Audio Input (Audio)
Coaxial SPDIF Input (Digital Audio)
Optical SPDIF Input (Digital Audio)
0.7 - 1.4V (Peak to Peak)
Stereo / Digital
0.4 - 4.8V (p-to-p)
75 ohm
Local country available
95 dBuV
75 ohm
6, 7, 8 MHz
20 dB typ.
36 dB typ.
MPEG2: 1080i / 720p / 576i / 480p / 480i
AVC (MPEG4): as above PLUS 1080p
H.264 AVC / MPEG2 MP@ML
MPEG1 Layer II / LPCM / AC-3 Pass through
Yes
2K / 8K
1/4, 1/8, 1/16, 1/32
1/2, 2/3, 3/4, 5/6, 7/8
16 QAM / 64 QAM
AC 100 - 240V (50/60Hz)
1250 mA
English
482.7mm x 240mm x 44.4mm
(19" x 9.45" x 1.75")
3.55 kg
RL-HD2000DM
HDMI Input (Video + Audio)
Y, Pb, Pr component Input (Video)
Composite Input (Video)
L/R Channel Audio Input (Audio)
Coaxial SPDIF Input (Digital Audio)
Optical SPDIF Input (Digital Audio)
0.7 - 1.4V (Peak to Peak)
Stereo / Digital
0.4 - 4.8V (p-to-p)
75 ohm
Local country available
95 dBuV
75 ohm
6, 7, 8 MHz
20 dB typ.
36 dB typ.
MPEG2: 1080i / 720p / 576i / 480p / 480i
AVC (MPEG4): as above PLUS 1080p
H.264 AVC / MPEG2 MP @ML
MPEG1 Layer II / LPCM / AC-3 Pass through
Yes
2K / 8K
1/4, 1/8, 1/16, 1/32
3/4, 5/6, 7/8
16 QAM / 64 QAM
AC 100 - 240V (50/60Hz)
1650 mA
English
482.7mm x 240mm x 44.4mm
(19" x 9.45" x 1.75")
3.75 kg
