Furniture of America CM-TR453 Assembly Instructions Manual

Download this manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM-TR453

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

(Not Included)

Rev: 18-03-12

Need help?

Do you have a question about the CM-TR453 and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-TR453 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Front Panel Bolt Ø1/4" x 1-3/8" #2 x 1pc #B x 8pcs Back Panel Washers Ø1/4"...
Page 4 Exploded View Align wheels (#E) to the bottom o the front and back panels (#1,2). Secure by using screws (#D). There will be no pre-drilled holes. #D x 8pcs #E x 4pcs Page 4 of 6...
Page 5 Align the side panels (#3) to the front and back panels (#1,2), then secure by using bolts (#A) with washers (#B). #A x 8pcs #B x 8pcs Align slats (#4) to the front and back panels (#1,2), then secure by using screws (#C).
Page 6 Place the bottom boards (#5,6) onto the trundle. Slide board stands (#7) through the grooves of the trundle. Page 6 of 6...
