Assembly Instructions
CM4401E
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 6
Rev.14-07-28
Advertisement
Related Manuals for Furniture of America CM4401E
Summary of Contents for Furniture of America CM4401E
- Page 1 Assembly Instructions CM4401E ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3 of 6...
- Page 4 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6 pcs #1 x 1 pc Bolt 5/16”x1/2” Glass Top #B x 8 pcs #2 x 1 pc Bolt 5/16”x3/4”...
- Page 5 Insert stand A (#2) through stand B (#3). Make sure the cutouts are aligned with each other. Insert the flat bracket (#H) through the cutout on the stand A (#2) and align with the pre-drilled holes on the stand B (#3). Prepare 2 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#E) onto the SAME bolt (#B), in that order.
- Page 6 Turn right (clockwise) to tighten #C x 4 pcs #D x 4 pcs #E x 4 pcs Align the base (#4) with the pre- drilled holes on the stand A (#2) and the stand B (#3). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#C) and then the flat washer (#E) onto the...
