Cerberus™ PRO
Zone module, external powered
FDCI723
A6V10402143_f_en_--
2018-10-03
Zone module, external powered, addressed for detector line C-NET.
●
Detector line (collective or conventional 110 series, DS11, SynoLINE300/600)
●
LED indicator for detector line status: fault, test, etc.
●
Two-wire installation for all cable types
●
DC 24 V power supply, external, tested to EN 54-4 (detector lines electrically
isolated)
●
Microprocessor-controlled signal processing
●
Communication via C-NET (addressed individually)
●
Can be used in dry, dusty, and humid areas
●
Different mounting options
Building Technologies
Control Products and Systems
Advertisement
Related Manuals for Siemens FDCI723
Summary of Contents for Siemens FDCI723
- Page 1 Cerberus™ PRO Zone module, external powered FDCI723 Zone module, external powered, addressed for detector line C-NET. ● Detector line (collective or conventional 110 series, DS11, SynoLINE300/600) ● LED indicator for detector line status: fault, test, etc. ● Two-wire installation for all cable types ●...
- Page 2 Properties Eco-friendly ● Environmentally friendly processing ● Reusable materials ● Electronic parts and synthetic materials can be easily separated Features ● Transparent housing, ensuring that LED indicators are easy to see ● Protected electronics ● Integrated line separator ● Easy mounting using snap fastener ●...
- Page 3 Name A6V10229261 List of compatibility (for 'Cerberus™ PRO' product line) A6V10414910 Technical manual Zone module, external powered FDCI723 Principles, applications, installation, maintenance Fire alarm signal in areas at risk of 001204 explosion Related documents such as the environmental declarations, CE declarations, etc., can be downloaded from the following Internet address: https://siemens.com/bt/download...
- Page 4 Notes Mounting ● Mounting on U-rail TS35 (series mounting) ● In housing FDCH221 with cover, seal, and screws Series mounting using mounting feet supplied, on U-rail TS35 Mounting in separate housing FDCH221 (accessory) Use auxiliary terminals DBZ1190-AB (accessory) for shielded cables Disposal The device is considered an electronic device for disposal in accordance with the European Guidelines and may not be disposed of as domestic...
- Page 5 Technical data FDCI723 C-NET operating voltage DC 12…33 V External power supply Tested to EN 54-4 ● Operating voltage DC 18...32 V Collective detector line ● Collective line code (KLK) ● End-of-line (EOL) 20 V voltage reference diode or EOL22 (Ex) Operating temperature -20...+55 °C...
- Page 6 Technical data: see doc. A6V10414910 FDCI723 - Input/output device incl. short-circuit isolator for use in fire detection and fire alarm systems installed in buildings. 305/2011/EU (CPR): EN 54-17 / EN 54-18 ; 2014/30/EU (EMC): EN 50130-4 / EN 61000-6-3 ; 2011/65/EU (RoHS): EN 50581 The declared performance and conformity can be seen in the Declaration of Performance (DoP) and the EU Declaration of Conformity (DoC), which is obtainable via the Customer Support center: Tel.
