Page 5: Installing The Keypad Light
INSTALLING THE KEYPAD LIGHT ® T2 Systems has developed a new LED light fixture to illuminate the keypad of your Luke II multi-space pay station. The light is designed to help the consumer make an easier keypad selection, especially at night if the unit is installed in a dimly lit location. - Page 6 4. Drill two holes into the cast using the drill with the 9/64in bit. 5. Drill one hole into the cast using the drill with the 3/8in bit. T2 Systems, Inc. T2systems.com...
- Page 7 7. Use the Door Inside drill template to mark the hole location to be drilled into the door. 8. Using the 1/2in bit, drill one hole into the door. You may want to drill a small pilot hole first to guide the larger drill bit. T2 Systems, Inc. T2systems.com...
- Page 8 10. To prevent rust, the hole in the door must be protected with a zinc-rich paint. If using a spray, use a mask so as to prevent over-spray onto electronic components and cables. Allow 30 minutes for the paint to dry. A mask template is provided at the end of this document. T2 Systems, Inc. T2systems.com...
-
Page 9: Install The Keypad Lighting Assembly
Carefully apply the marine grease to the three holes in the front cast using a Q-tip. Install the Keypad Lighting Assembly Tool Required Phillips screwdriver Parts 1x Keypad Lighting Module 1x Cable, Keypad Lighting 1x Diffuser, Keypad Lighting T2 Systems, Inc. T2systems.com... - Page 10 PCB tail into the hole and through the grommet. b. Be sure not to twist or crease the flex PCB as it is being guided through the holes. T2 Systems, Inc. T2systems.com...
- Page 11 3. Attach the lighting assembly to the cast using the 2x #8 screws. 4. To attach the lighting cable, first disconnect the white LCD backlight connector. Then connect the keypad lighting adapter cable to the LCD backlight, and the other end to the disconnected backlight cable. T2 Systems, Inc. T2systems.com...
- Page 12 9. Restore power to your pay station. The keypad light will activate once the pay station starts up. The light will turn off when the pay station goes into sleep mode and will turn on again when a key on the keypad is pressed. T2 Systems, Inc. T2systems.com...
- Page 13 Luke II Keypad Lighting Installation Guide ® This completes the installation of your keypad light. T2 Systems, Inc. T2systems.com...
-
Page 14: Appendix A - Mask Template
Luke II Keypad Lighting Installation Guide ® APPENDIX A – MASK TEMPLATE T2 Systems, Inc. T2systems.com... - Page 15 1"...
- Page 16 II Keypad Lighting Installation Guide ® For Assistance or More Information For any questions concerning procedures outlined in this Installation Guide, please contact T2 Technical Support at 1-888-687-6822 ext. 6426 or 604-688-1959 ext. 6426, or e-mail digital.support@t2systems.com. T2 Systems, Inc. T2systems.com...
