CONNECTING YOUR COOLBOT PRO TO YOUR AIR CONDITIONER

See installation diagram on page 3.
NOTE: If you are connecting the CoolBot Pro to a Wi-Fi network follow page 2 first.
STEP 1 Plug the cables into the corresponding labeled ports at the bottom of the CoolBot Pro except for the Data Cable. If you are
replacing an existing CoolBot with "removable" cables, use all your new cables and save the old cables as spare parts. The
CoolBot Pro works with both black and blue Temperature Sensor Cables.
STEP 2 Mount the CoolBot Pro on the wall next to the A/C, preferably on the same side as the A/C's control panel.
STEP 3 REMOVE THE AIR FILTERS from the front of the A/C – DO NOT use them!
STEP 4 Find and free the A/C's main Temperature Sensor. It's the only thing attached to the front grill of the A/C. Take the sensor
out of the mounting clip - DO NOT use the mounting clip for your CoolBot sensors installation.
STEP 5 Using ONLY a 2" square piece of regular Aluminum foil, place the CoolBot Heater Cable (Red Tip) next to the A/C's main
Temperature Sensor. Hold them together and wrap them tightly with the foil into a bundle. You can use a Zip-tie or a piece
of tape 1 inch below the foil bundle to keep them together. Make sure the foil bundle does NOT hang in front of the A/C - it
should hang to the side or below the A/C.
STEP 6 If you have an LG (except newer Inverter Models) or a HAIER window A/C unit skip to STEP 7.
Most brands of Window A/C units and most Mini-Split units have Secondary Sensors.
To find the A/C's Secondary Sensor please visit our support page at: www.storeitcold.com/support.
If you found a Secondary Sensor, place the secondary sensor on top of the foil bundle from step 5 (not inside) and hold it in
place with a small piece of electrical tape – do not over insulate the foil bundle while doing this, use ONLY one layer of tape.
STEP 7 Use a pen or a pencil to open a small gap in the front of the fins of the A/C about 1" from the bottom and near the center,
between the bottom and second Cooling pipes.
Insert ONLY ¼" of the tip of the CoolBot Fins Sensor into the small gap.
DO NOT force the sensor in, you will damage it! DO NOT touch any Cooling Pipes with the Fins Sensor- only the fins!
Pinch the fins lightly around the sensor to keep it in place.
STEP 8 If you are not connecting your CoolBot Pro to a Wi-Fi network, skip this step and go to Step 9. Mount the CoolBot Jumper
outside of your cooler in a location close enough for the provided Data Cable (~25ft) to connect the CoolBot Jumper to the
CoolBot Pro. The CoolBot Jumper is not weatherproof. If it is to be mounted outdoors where rain, snow, and sunlight may
get to it, then install it inside of a weatherproof nonmetallic container. After the CoolBot Jumper is mounted, connect the
CoolBot Pro and the CoolBot Jumper using the provided Data Cable.
STEP 9 Turn your A/C ON. Set the A/C on "COOL" Mode and set the Fan on "HIGH" speed. Set the A/C temperature to the lowest
setting. If your A/C has a separate Economy Mode make sure is OFF. The Fan should run continuously!
STEP 10 Plug in your CoolBot Pro power supply. To set the temperature on your CoolBot Pro, press the checkmark button – the
current set temperature will blink. Use the right or left arrows to set the temperature to the desired value. Press the
checkmark to save the value.
https://www.instagram.com/storeitcold
https://www.youtube.com/storeitcold
CoolBot Pro Quick Start Set Up Guide Rev 2020 – 01A UL
Detailed CoolBot Pro Installation Video, Instruction Manual, App Features,
Specification Sheets and Troubleshooting at:
www.storeitcold.com/support
