5 FSZ Basis – technical data
5 FSZ Basis – technical data
Nominal voltage
Nominal current consumption
Rated frequency
Power consumption
Nominal output voltage
Residual ripple
Output current
Output power
Relay
Switching voltage AC
Switching current AC
Switching voltage DC
Switching current at 30 V DC
Switching current at 24 V DC
Operating ambient temperature
Storage temperature
Ambient conditions humidity
(continuous, without condensation) ≤ 34 °C
Ambient conditions humidity
(continuous, without condensation) > 34 °C
Degree of protection with exposed assembly
Degree of protection with cable entry from behind
Safety class
Housing
Colour
Installation
Installation position
8
1 alternating contact, potential-free
-10 °C to +50 °C
-10 °C to +60 °C
PC-ABS housing
signal white according to RAL 9003
exposed assembly
230 V AC
0.08 A eff.
50/60 Hz
13.8 VA
24 V DC
200 mV
SS
max. 400 mA
9.6 W
max. 250 V AC
max. 5 A AC
max. 30 V DC
max. 3 A DC
max. 5 A DC
10 ... 95 % RH
max. 35 g/m³
min. 10 % RH
IP 65
IP 30
"I"
as desired
