Hekatron Standard X Operating Manual

Hekatron Standard X Operating Manual

Radio module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating manual
Standard X radio module

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Standard X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hekatron Standard X

Summary of Contents for Hekatron Standard X

  • Page 1 Operating manual Standard X radio module...
  • Page 3 Behaviour in the event of fire 1. Rescue people slots and try to attract someone’s attention at the window. f Warn the people living with you. f Immediately leave the room / 2. Call the fire brigade the building and close all doors f Wait until you are on your way out to prevent a rapid spread of...

  • Page 4: Table Of Contents

    4 | Contents Contents 1. Introduction 2. Intended use 3. Safety 4. General information 5. Product description 5.1 Functional principle 5.2 Features 6. Project planning 6.1 General 7. Assembly 8. Radio commissioning 9. Operation 9.1 Locating and deactivating a fault 9.2 Locating and deactivating an alarm 9.3 Preventing transmission of alarms 9.4 Adding users to the radio network/replacing smoke alarms...
  • Page 5 9.5 Removing users from the radio network 9.6 Deleting line allocations 10. Status signals 11. Maintenance 11.1 Line test 12. Disposal 13. Environment 14. Terms of use 15. Product complaints 16. Technical data...

  • Page 6: Introduction

    Genius bination with a smoke alarm, the Plus X with the Standard X radio operating manual for the Genius Plus module: X or Genius Hx apply in addition.
  • Page 7 1. Introduction | 7 This manual uses the following symbols and signal words: Symbol/ Keyword Meaning CAUTION Warning which could lead to material damage or functional defects if it is not observed Reference to additional information Instruction Result of an action Ö...

  • Page 8: Intended Use

    2. Intended use The radio module is designed If the radio module is not used as „ exclusively for use with the intended, Hekatron Vertriebs GmbH Genius Plus X and Genius Hx shall not assume any liability for smoke alarms. resulting damage.

  • Page 9: Safety

    3. Safety | 9 3. Safety Smoke alarm with Standard X „ radio module: If the safety and operating Improper assembly, commission- instructions are not observed, ing and maintenance of smoke no liability and warranty claims alarms with radio modules may...

  • Page 10: General Information

    10 | 4. General information 4. General information This chapter explains important Repeater general terms and information. Each radio module is equipped with These are important for a better a repeater that receives signals and understanding of all subsequent then transmits them at maximum chapters.
  • Page 11 4. General information | 11 Signal propagation time The signal propagation time within a radio network depends on the number of users and the number of signals currently in circulation: Radio network Signal propagation No signals Approx. 5 to 10 seconds Signals in Max.

  • Page 12: Product Description

    12 | 5. Product description 5. Product description Rubber rings for fixing Red operating button Radio module LED Standard X radio module...

  • Page 13: Functional Principle

    5. Product description | 13 5.1 Functional Conformity principle Hekatron Vertriebs GmbH hereby declares that the Standard X Every radio module is equipped radio module is compliant with with an integrated repeater that EU regulations 2014/53/EU receives signals and then transmits and 2011/65/EU.

  • Page 14: Project Planning

    14 | 6. Project planning 6. Project planning Also comply with the following additional aspects: 6.1 General connection of max. 30 radio „ smoke alarms per line All specifications in the operating manual of the smoke alarm shall distance between 2 radio users: „...

  • Page 15: Assembly

    7. Assembly | 15 7. Assembly f Mount the smoke alarm base. For this purpose, observe the CAUTION specifications in the operating manual of the smoke alarm and Risk of damage to the radio module in the chapter "Project planning" f Do not touch components in this manual.
  • Page 16 16 | 7. Assembly f Fix the radio module to the CAUTION connector pins using the rubber If smoke alarms with a radio module rings. are screwed into the base, but no Ö The radio module LED flashes radio commissioning is carried out for approx.

  • Page 17: Radio Commissioning

    8. Radio commissioning | 17 8. Radio commissioning Radio commissioning is carried out Performing radio commissioning for each line, i.e. each line must be After the start of commission- commissioned separately. If 2 A.0 ing, all users of this line lines are to be operated in parallel, must be confirmed within 2 radio commissioning operations...
  • Page 18 18 | 8. Radio commissioning 15 minutes by flashing green Ö The smoke alarms receive a on the test button and a unique ID. triple acoustic signal every Ö Radio commissioning is 8 seconds. complete. The network- f All smoke alarms of this line must connected smoke alarms go be confirmed within 15 minutes into normal operation and...

  • Page 19: Operation

    9. Operation | 19 9. Operation 9.2 Locating and deactivating an 9.1 Locating and alarm deactivating a fault Locating an alarm f Press the test button on a Locating a fault signalling smoke alarm. f Press the test button on a Ö...

  • Page 20: Preventing Transmission Of Alarms

    20 | 9. Operation 9.3 Preventing 9.4 Adding users to transmission of the radio alarms network/replacing smoke alarms If a radio smoke alarm detects a fire, the signal is transmitted to the radio Single or several users can be added network after about 20 seconds.
  • Page 21 9. Operation | 21 f Confirm each new user by radio commissioning by means of the running light ( green-orange- pressing its test button. red ) on the test button every Ö The users each signal 8 seconds. successful registration on the line by a triple acoustic signal Adding / replacing users and green flashing of the test...

  • Page 22: Removing Users From The Radio Network

    22 | 9. Operation 9.5 Removing users f Briefly press the red operating button at the radio module. from the radio Ö Radio commissioning is network terminated. Ö The smoke alarms stop f Remove the desired radio smoke signalling. alarm form the base. Ö...

  • Page 23: Deleting Line Allocations

    9. Operation | 23 9.6 Deleting line allocations In order for a smoke alarm to be taught-in to another line, its ID and assignment to the current line must first be deleted. f Remove the radio module from the smoke alarm for approx. 20 seconds.

  • Page 24: Status Signals

    24 | 10. Status signals 10. Status signals Normal operation The smoke alarm has an integrated In normal operation, the smoke real-time clock. This has the effect alarm carries out an automatic that the LED in the test button and self-check in regular intervals.
  • Page 25 10. Status signals | 25 Normal operation ( continued ) Test button Acoustic alarm Cause Remedy GREEN- Running Short acoustic No radio Commission the radio ORANGE- light every signal every networking ( radio module. 48 seconds 48 seconds module LED is off ) ORANGE Flashes every Short acoustic...
  • Page 26 26 | 10. Status signals Fire alarm As soon as the smoke alarm detects smoke, it enters the “fire alarm” mode. In this mode, the LED is flashing, and the acoustic alarm is sounded. Acoustic Test button Cause Remedy alarm Flashes every Alternating, Smoke is detected Exit the building...

  • Page 27: Maintenance

    11. Maintenance | 27 11. Maintenance 11.1 Line test To be able to guarantee the The line test checks whether all impeccable function of the smoke smoke alarms in a line with the same alarm incl. radio module, an on-site ID are within range and functional.

  • Page 28: Disposal

    28 | 12. Disposal 12. Disposal self-test sound and a single green flashing of the LED. Every consumer is legally obliged to After 15 minutes, the return all electrical and electronic triple acoustic signal stops equipment via the municipal automatically on all smoke collection points.

  • Page 29: Environment

    13. Environment | 29 13. Environment 14. Terms of use Our Standard X radio modules are If the following terms of use are manufactured in compliance with complied with, this radio module the quality and environmental has a typical service life of up to management standards according 10 years.

  • Page 30: Product Complaints

    30 | 15. Product complaints 15. Product Maximum alarm time per year: „ complaints 90 seconds Max. 12 functional tests or data „ transmissions via “Smartsonic” Our radio modules meet the highest per year quality requirements. Should you nevertheless have any reason to Genius Plus X with radio module complain, please directly contact your dealer.

  • Page 31: Technical Data

    16. Technical data | 31 16. Technical data Approved by VdS VdS 3515 / G-Number G 215027 / G 219068 Battery life typically 10 years Supply voltage via smoke alarm Frequency band SRD band Frequency range 868.3 MHz Antenna type PCB antenna Range min.
  • Page 32 Obliged to safety. The protection of people and material assets in the event of a fire has al- ways been the main objective of Hekatron Brandschutz. We are the leading provider of technical fire protection systems in Germany and your num- ber-one partner in this field.
