Whirlpool ED2FHEXVB00 Parts List page 8

MOTOR AND ICE CONTAINER PARTS
For Models: ED2FHEXVQ00, ED2FHEXVT00, ED2FHEXVB00, ED2FHEXVL00, ED2FHEXVS00
(White) (Biscuit) (Black)
Illus. Part
No. No. DESCRIPTION
1 2183728 Bracket, Motor
2 2188385 Motor, Dispenser
3 2152713 Soleniod Assembly
4 2149100 Guide, Solenoid
5 489355 Screw (2)
6 2311639 Wiring Assembly,
Ice Dispenser
7 489399 Screw (6)
8 2205716 Coupling, Motor
9 489478 Screw
10 2162085 Socket, Light
11 2196089 Ice Container
12 1119005 Spacer, Step (3)
13 1119007 Spacer, Flat (2)
14 2257022 Blade, Rotary
15 2257023 Blade, Rotary
16 2257024 Blade, Rotary
17 489235 Washer, Plain
18 1119009 Blade, Fixed (2)
19 2157405 Block, Blade
20 489229 Roll Pin
21 2196295 Auger
22 2209781 Drum
23 2171682 Floating Baffle
24 1119018 Nut, Bearing
25 2155231 Control Arm
26 1119020 Spring, Return
27 1119021 Retainer Clip, Rod
28 488886 Screw
29 2180348 Housing, Crusher
30 1119017 Deflector, Ice
31 489234 Washer, Plain
32 489236 Retainer Ring
33 2171709 Front Cover,
Ice Container
34 2311792 Light Bulb
35 2171706 Light Lens,
Dispenser
100 2209779 Ice Container
(Complete)
8
(Stainless VCM) (Stainless)
W10177406
