Whirlpool ED2FHEXVB00 Parts List page 20

For Models: ED2FHEXVQ00, ED2FHEXVT00, ED2FHEXVB00, ED2FHEXVL00, ED2FHEXVS00
(White)
ICEMAKER PARTS
(Biscuit) (Black)
Illus. Part
No. No. DESCRIPTION
1 489084 Screw
2 2209774 Chute, Water
3 628379 Clip, Fuse
4 2304859 Tube, Water
5 489478 Screw
6 2304833 Filter Valve Asm
7 489385 Tube Clip
8 2174155 Cover
9 488649 Screw (2)
10 628228 Mold & Heater
Assembly (Also
Order 542638
11 628356 Cup, Water Fill
12 627843 Ejector
13 2182124 Ice Striper
14 2194712 Support
15 2315522 Retainer,
Thermostat
16 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
17 8533917 Screw
18 489276 Screw
19 2304354 Shut Off Arm
20 628320 Bracket
21 626678 Module Assembly
22 488208 Screw
23 Motor
(Not Serviced,
Order #21)
100 626662 Complete Icemaker
Assembly
20
(Stainless VCM) (Stainless)
W10177406
