Whirlpool ED2FHEXVB00 Parts List page 6

FREEZER LINER PARTS
For Models: ED2FHEXVQ00, ED2FHEXVT00, ED2FHEXVB00, ED2FHEXVL00, ED2FHEXVS00
(White) (Biscuit) (Black)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 1115380 Slide, Ice Door
3 2171712 Door, Ice
Compartment
4 2309634 Shelf, Wire
5 489478 Screw
6 842534 Clip, Air Duct (2)
7 2196206 Support, Stud (4)
8 2309758 Freezer Bin
9 1115373 Switch, Rocker Arm
10 2309633 Shelf, Wire
11 2196206 Stud, Rear
12 Slide, Container
1119237 Left Side
1119293 Right Side
13 489100 Screw (4)
14 3400893 Screw
15 2309632 Shelf, Wire
6
(Stainless VCM) (Stainless)
W10177406
