Power Flame C Series Installation & Operation Manual page 53

2001 South 21st St., Parsons, KS 67357, 620-421-0480, 620-421-0948 FAX
POWER FLAME INCORPORATED
10. OWNER OPERATING INSTRUCTIONS
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Do not touch electrical
switches.
Do not store or use gasoline or other flammable liquids and
vapors in the vicinity of this or any other appliance.
IMPORTANT PRECAUTIONS
1. Never attempt to light burner with paper or other
materials.
2. Never experiment with the burner.
3. Never change the fuel or air adjustments without
consulting with the burner service company.
START UP
Preparation for Start Up - All Fuels
1. Ensure that the system is in working order. If heat
exchanger is a boiler, ensure that proper water level
is available.
Oil burner - make sure that the oil tank has an ad-
equate fuel level and that the fuel is the proper grade.
2. Set the burner control panel switch to the OFF
position.
Start Up - Gas Burner
1. Manually open and close the main gas shut off cock,
leak test cock and pilot cock to determine that they
operate freely. Open all three cocks. (Reset low gas
pressure switch if supplied.)
2. Set the main power switch and burner panel control
switch to the ON position. Wait 30 seconds and
turn up thermostat or operating control to the
desired setting.
3. The burner blower motor will start and after a suitable
prepurge period (this will vary with the type of flame
Start Up - Oil Burner
1. Open all valves in oil lines.
2. If pilot gas ignation system is supplied - open and
close the pilot gas cock to determine that it is operating
freely. Open the pilot gas cock.
3. Set the main power switch and burner panel control
switch to the ON position. Wait 30 seconds and
turn up thermostat or operating control to the
desired setting.
EXTENDED SHUT DOWN
1. Place main power switch and burner control panel
switch to the OFF position.
2. Close all valves in gas and oil lines.
3. Cover burner to protect it from dust and dampness.
Burner Service Company
Address
3. Extinquish any open flame.
4. Call your gas supplier
immediately.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Refer to the burner manual. For assistance or additional
information consult a qualified installer, service agency
or the gas supplier.
4. Never attempt to light the burner if combustion
chamber contains any unburned fuel or gases.
5. Never throw waste paper, rags, garbage, or other
waste materials into the combustion chamber.
6. Never wash out heating equipment room without first
covering the burner with waterproof material.
Combination Gas/Oil burner - Set the fuel selector
switch to the fuel to be burned.
3. Turn the thermostat or operating control down to its
lowest setting.
4. Check fuses and replace as necessary.
5. Depress the flame safeguard programming control
reset button.
safeguard control supplied - but will usually be a
minimum of 30 seconds to a maximum of 90 seconds)
the burner pilot will light, after which the main flame
will be established.
4. If the system does not respond properly, contact your
qualified burner service company.
5. When burning gas on a Combination Gas/Oil unit
that has a blower motor driven oil pump, open all oil
line valves. Oil must circulate through the oil pump,
even when burning gas.
4. The burner blower motor will start. Depending upon
the type of flame safeguard control supplied, the fuel
ignition system may energize within 1 or 2 seconds
after the blower motor starts or could be as long as 90
seconds.
5. If the system does not respond properly, contact your
qualified burner service company.
MAINTENANCE
1. See Maintenance section in burner manual for
suggestions on periodic maintenance and service.
Date of Installation
Telephone
C51
®
Rev.304
