MANUAL C888
CONTENTS
1
2
2
2
3
General Component Information
3
On-Off Fuel/Air Control Modes
4
Fuel/Air Control Modes
4
Burner Component Identification
Modulating Fuel/Air Control Modes
5
6
7
9
9
Gas Supply Line Sizing Charts
10 Gas Train Piping Schematics
for Standard UL Burner
Requirements
11 Oil Supply Piping - General
Filter Selection Information
12 Oil Line Sizing Charts
1.
GENERAL PRODUCT INFORMATION
Principal of Operation
Power Flame Type C Burners incorporate the principles of
pressure atomization for oil and multiple orifice, venturi
operation for gas. The total package utilizes the forced
draft, flame retention concept. The Type C burner is listed
and labeled by Underwriters Laboratories, Inc. Capacities,
when fired at 0.2" w.c. positive combustion chamber
pressure, range from 3 to 136.4 GPH of commercial grade
#2 fuel oil and/or 98 to 19,100 CFH of natural gas. Air for
combustion is furnished by an integrally mounted combus-
tion air fan. The Power Flame packaged combustion
system can be operated under positive or negative furnace
pressures with clean, efficient combustion in a wide range
of combustion chamber conditions. (Consult page 6 for
appropriate ratings.)
Power Flame Type C Burners are designed to produce
greater flame turbulence and reduce flame size. As a
result, they require less combustion volume for complete
combustion and can be easily fired under positive furnace
pressure. Forced draft pressurized operation requires
stacks of smaller diameter and height.
Rev. 304
Fuel/Air Control Modes
15 Gas - Low-High-Off and Low-High-Low
16 Gas - Full Modulation
16 Oil - On-Off
17 Oil - Fixed Air Low Fire Start
18 Reduced Air Low Fire Start System
19 Oil - Low-High-Off and Low-High-
Low with Webster Oil Pump
20 Oil - Low-High-Off and Low-High-
Low with Suntec 2-Step Oil Pump
21 Oil - Full Modulation
22 Diffuser Position Adjustment for Gas,
Oil or Gas/Oil Burners
22 Gas or Gas/Oil Burner Fuel/Air
Premix Adjustment
22 Gas/Oil - Linkage Arrangement for
Full Modulation - Standard System
22 Gas/Oil - Detail and Adjustments on
Modulating Varicam
Fuel Metering System
4. Start Up, All Fuel
25 General Gas Start Up Procedure
6. Oil Start Up
28 General Oil Start Up Procedure
The Power Flame C Burner is a totally packaged and
factory tested combustion system offering single unit
responsibility. The package incorporates accurate control
of the fuel-air ratio throughout the firing range with the
resultant controlled flame patterns and clean combustion
for maximum efficiency.
Combustion air flow is controlled by a multi-louvered
damper assembly. The combustion air is supplied by an
integral motor-driven blower, which discharges into the
burner blast tube assembly. High turbulence flow is
controlled by means of an adjustable fan diffuser system.
Various system mode operations are obtained by
applying appropriate control valves and fuel/air actuators.
Units are capable of operating in modes consistent with
specific demand requirements, from fixed or on-off through
full modulation.
The air/fuel ratio is established at the time of start-up and
proven with combustion test equipment to provide the
lowest practical oxygen with a clean flame.
35 Oil Drawer Assembly Diagrams
Cutaway
36 Gas and Gas/Oil Gun Assembly
Diagrams
37 Gas Burner Orifice Sizing
38 Limiting Orifice Information
Signal Values
41 CO
Oils and Gases
44 General
46 Combustion Analysis
51 10. Gas and Oil Burner Owner
C1
Rev.304
