Control Settings - Power Flame C Series Installation & Operation Manual

Control Settings

General
Operating control cut out setting
Operating control cut in setting
Limit control cut out setting
Limit control cut in setting
Operation Checklist
Checked For Proper Operation of:
Low water cut off
High water cut off
Flame safeguard control ignition failure
Flame safeguard control main flame failure
Burner air flow switch
Induced draft fan controls
Over fire draft controls
Fresh air damper end switch
Notified
NOTES
Gas
Low gas pressure switch
High gas pressure switch
Yes No
( ) ( ) Barometric damper
( ) ( )
Boiler room combustion air and ventilation
provisions correct
( ) ( )
Oil tank vent system checked
( ) ( )
All oil lines checked for leaks
( ) ( )
All gas lines checked for leaks
( ) ( )
( ) ( ) Gas lines and controls properly vented
( ) ( ) Other system components (specify)
of following system deficiencies:
Oil
in. Low oil pressure switch
in. High oil pressure switch
C47
Rev.304
lbs.
lbs.
Yes No
( ) ( )
( ) ( )
( ) ( )
( ) ( )
( ) ( )
( ) ( )
( ) ( )
