- Page 2 Welcome to: ADDAC106 T-NOISEWORKS USER’S GUIDE Revision.01 March.2020 OVERALL FEATURES This is the last module in our T-Networks series, a straight forward 4 voice module with frequency and decay controls for each of the voices. As the name already unveils we added a noise source and created 2 different circuits that explores the timbre of a t-network when used to filter noise.
- Page 3 Sets amount of decay voice Low/Mod/High range switches Sets the Frequency Range Summing Mix Gain Sets the output gain for the overall Summing Mix Output summing mix Independent voice input settings Independent voices outputs Independent voices inputs ADDAC SYSTEM page 3...
- Page 4 SLEW INPUT 1 TRIGGER MIX VOLUME DECAY OUTPUT 1 VOICE 2 AUDIO SUM VOICE 3 VOICE 4 RANGE FREQUENCY MIX OUTPUT H / M / L T-NETWORK ENVELOPE MUTE SLEW INPUT 4 TRIGGER DECAY OUTPUT 4 ADDAC SYSTEM page 4...
- Page 5 For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC106 USER’S GUIDE Revision.01 March.2020...
