- Page 2 ADDAC106 Assembly Guide March.2020 ADDAC SYSTEM page 2...
- Page 3 Then solder the other pad. 2.2uF 10uF ADDAC SYSTEM page 3...
- Page 4 ADDAC106 Assembly Guide STEP 2: Next place and solder the 78L05 voltage regulator, notice the orientation printed on the pcb. Then proceed to place and solder the IDC connector, also notice the orientation printed on the pcb. ADDAC SYSTEM page 4...
- Page 5 ADDAC106 Assembly Guide STEP 3: Next place the spacer like shown below. ADDAC SYSTEM page 5...
- Page 6 ADDAC106 Assembly Guide STEP 4: Next place and solder all pinheaders like shown below. ADDAC SYSTEM page 6...
- Page 7 Next we’ll need to prepare some parts before adding them to the front panel. Locate all trim pots and flatten out their legs with the help of some pliers, like shown below. STEP 6: Locate the jacks and cut the smallest legs like shown below. ADDAC SYSTEM page 7...
- Page 8 Notice the values of all Pots and the 2 or 3 position switches locations. All switches shoud have a nut on, raised aprox. 1mm from the lowest position. 2 POSITION B1M (B105) B1M (B105) B100k (B104) 3 POSITION A10k (A103) 2 POSITION 3 POSITION KNURLED JACKS ADDAC SYSTEM page 8...
- Page 9 ADDAC106 Assembly Guide STEP 8: After all parts are in place, fit the frontpanel in and tighten all the nuts. Proceed by soldering all the pads in the back. ADDAC SYSTEM page 9...
- Page 10 ADDAC106 Assembly Guide STEP 9: For the last step attach the back pcb and place the bottom screw. ADDAC SYSTEM page 10...
- Page 11 ADDAC106 Assembly Guide Congratulations, you’re done! Happy Patching! ADDAC SYSTEM page 11...
-
Page 12: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC106 ASSEMBLY GUIDE Revision.01 July.2020...
