Hardware Overview Part I
Back Panel
Power Button
DC Port
USB Port
Ethernet Port
Port
DC Port
Power Button Switch ON/OFF for power
Reset Button
USB Port
Ethernet Port
HDMI Port
Description
Connect to 5V/2A Universal Adapter
After powering up, press and hold the reset
button to reset to factory default setting
For USB HID Reverse Control
Support PoE and Gigabit internet access by
connecting to RJ45 cable
Support HDMI Output by connecting to HDMI
A to A cable
Reset Button
HDMI Port
