- Page 1 Wine Cooler JC-201 Instruction Manual CCI145DB NOTE : Thank you for your purchase and use our compressor wine cooler ！ Our product will create perfect temperature and humidity environment to store your collection of wine quietly and peacefully.
-
Page 2: Table Of Contents
Content Safety instructions & warnings………………………………..…………………………….1-2 Installation………………………………..……………………………………………………………3 Description of the appliance………………………………..………………………………..4-5 Operation………………………………..…………………………………………………………….6-8 Troubleshooting………………………………..…………………………………………………..9 Maintenance and cleaning………………………………..……………………………………10 Technical parameters………………………………..…………………………………………..11... -
Page 3: Safety Instructions & Warnings
Safety instructions & warnings Your safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Technical Department. - Page 4 Unplug the appliance under Child Safety certain conditions ●Do not allow child play inside the ●Unplug the appliance before cleaning & appliance in case of entrapment. maintenance. ●Do not allow child hang on the door to ●Unplug the appliance when power cut play in case of falling of the appliance.
-
Page 5: Installation
Installation Position Do not lean the appliance over 45°when moving it to position. The appliance must be put on flat,firm & dry floor or similar noncombustible pad; do not use the package foam pad. 酒柜结构及安装示意图 Do not put the appliance in the wet place. Do not use the appliance in the frozen place. -
Page 6: Description Of The Appliance
Description of the appliance Accessories& name 11. Upper hinge 1. Housing 10. Door seal 2.Shelf 3. Control panel 9. Handle 4. Cover board 5. Grill 8. Door 6. Adjustable foot 7. Lower hinge Note: Shelves, door frame, handle and other accessories could be different according to different models and configuration.All photos in this manual are for reference. - Page 7 Reversing the door Our wine cooler is delivered with the door opening from left to right. To reverse the opening direction: ² Open the door at 90 degrees and keep it steady. ² Unscrew the two screws①from the right lower hinge②[Figure 1]. ²...
-
Page 8: Operation
Operation Start operation 1. Cleaning the compartment Before power on, clean inside of the appliance and check the drainage pipe in good connection.（For details, please refer to the “Maintenance and cleaning”） 2. Put the appliance still Before power on, level the appliance on the firm & dry floor for at least 30 minutes. 3. - Page 9 Down Press the key once, LED Display in regular flash showing current set temperature. Continue pressing to adjust set temperature, one press reduce 1℃. Regular flash quit after 5 seconds detecting no press and new set temperature save. LED display return to show actual temperature inside. Child Lock （...
- Page 10 Wine storage ² The appliance equip with sufficient independent shelf to allow your collection of wine get mature quietly and peacefully. ² 5 beech wooden shelves loading capacity: 46 bottles. (standard Bordeaux with 750ml ) ² Loading capacity will vary in terms of different way of bottle arrangement or different bottle sizes.
-
Page 11: Troubleshooting
Troubleshooting The appliance makes lots l Please adjust the front foot, keep the appliance of noise? leveling. l Please keep the appliance a bit space from walls. Liquid flowing sound l It is normal because of the refrigerant working inside the cabinet? inside. -
Page 12: Maintenance And Cleaning
Maintenance and cleaning Cleaning Ø Disconnect the appliance before cleaning. Ø Clean the appliance with soft cloth or sponge by water. Ø Do not use organic solvents, alkaline detergent, boiling water, washing powder or acid liquid etc. Ø Do not flush the compartment of the appliance. Ø... -
Page 13: Technical Parameters
Technical parameters Product model CC145DB Voltage/frequency 220-240V～/50Hz Refrigerant/weight R600a/35g Effective volume 129L Loading capacity 46 bottles Net weight 45.5 kg Unit dimension 595×570×865mm (WxDxH) Packing dimension 660×625 x 925mm (WxDxH) Remarks： 1. The Net weight includes shelves and the Unit dimension is without handle on the door.
