Hokkaido HMCZ 95 F User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Portable Air Conditioner
HMCZ 95 F
User Manual
2015
www.hokkaido.it
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HMCZ 95 F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hokkaido HMCZ 95 F

Summary of Contents for Hokkaido HMCZ 95 F

  • Page 1 Portable Air Conditioner HMCZ 95 F User Manual 2015 www.hokkaido.it - 1 -...

  • Page 2: Table Of Contents

    Table of Contents GENERAL INFORMATION ...................... 3 SAFETY PRECAUTIONS ......................7 NAME OF THE PARTS ......................10 CONTROL PANEL ........................11 IR REMOTE CONTROL ......................14 UNIT’S OPERATION ......................15 CLEANING & MAINTENANCE OF AIR CONDITIONER ............17 CORRECT USE OF AIR CONDITIONER ................18 TROUBLESHOOTING ......................

  • Page 3: General Information

    Thank you for showing confidence in our Product. We hope you enjoy a pleasant room climate with your Mobile Air Conditioner HMCZ 95 F. EASY TO OPERATE AND EASY TO MOVE AROUND •...
  • Page 4 GENERAL INFORMATION UNPACKING INSTRUCTIONS Place the Unit in the correct upright position before unpacking. Cut the two packing straps. Slide the carton in an upwards motion and it will release from the base. Grip the carry handles located on either sides of the Unit and carefully lift until it slides out of the foam base.
  • Page 5 GENERAL INFORMATION EXHAUST HOSE INSTALL Please according to the arow direction of the figure “ 1 “, rotate the exhaust duct, the exhaust duct can be installed pipe on the unit. Please according to the arrow direction of the figure " 2 ", rotate the exhaust duct, the ­...
  • Page 6 GENERAL INFORMATION BEFORE OPERATING THE UNIT VERY IMPORTANT! Do not install and use your Portable Air Conditioner Unit before carefully reading this instruction guide. Please retain this Manual brochure for product warranty and future reference. CAUTION PLEASE MAKE SURE THE PRODUCT VENTILATES ALL THE TIME! Please make sure the inlet and outlet ventilation is not blocked at all times.

  • Page 7: Safety Precautions

    SAFETY PRECAUTIONS • To take best advantage from your new air conditioner and for correct operation, please read carefully this Manual. • Hazard and safety levels are shown via warning and alert signs as listed below. May result in life-threatening danger or severe injury if Warning operated incorrectly.
  • Page 8 SAFETY PRECAUTUIONS Caution • N e v e r b l o c k t h e • The air conditioner blowout vent or intake is designed for indoor use; exposure to direct vent with clothing or sunlight or rain may rags.
  • Page 9 SAFETY PRECAUTIONS Warning • Keep the power plug • Never turn on and off clean from dust and the air conditioner by plugging and unplugging make sure it is securely the power tap from the inserted into the wall wall receptacle. receptacle.

  • Page 10: Name Of The Parts

    NAME OF THE PARTS OUTLINE OF MOBILE AIR CONDITIONER HMCZ 95 F 1. Control panel 2. Remote control receiver 3. Hot air-outlet 4. Evaporator’s filter 5. Cool air-inlet 6. Air outlet’s joint part (accessory supplied with the Unit) 7. Cool air-outlet 8.

  • Page 11: Control Panel

    CONTROL PANEL CONTROL PANEL & DESCRIPTION OF FUNCTION POWER KEY Press this button to switch on/off the Unit. FUNCTION Press this button to select the functions “Cooling” , “Heating” or “Dehumidify”. TEMPERATURE REGULATION KEY (UP) In “Cooling” mode, every time the button is pressed, temperature rises by 1°C, up to a maximum value of 30°C.
  • Page 12 PROGRAMMABLE TIMER Button for selecting programmable automatic start/stop of Mobile Air Conditioner HMCZ 95 F. Time interval for automatic start: This function is used for automatic start of Unit at the end of set time interval. Proceed in the following way: 1.
  • Page 13 OPERATING PANEL of set time interval. Proceed in the following way: 1. During Unit’s operation, press TIMER button to select time interval (number of hours) at the end of which Unit will automatically stop operation. 2. As soon as set time interval (number of hours) has expired, Unit automatically stops operation.

  • Page 14: Ir Remote Control

    IR REMOTE CONTROL REMOTE CONTROL FUNCTION On/Off switch. Function “MODE” selector. Hourly programming. Automatic fan speed. High fan speed. Medium fan speed. Low fan speed. Night operation selector. Temperature selector. - 14 -...

  • Page 15: Unit's Operation

    UNIT’S OPERATION OPERATION MODE This Unit has a self-evaporating function for condensation water, so that it is normally not necessary to empty the water tank in “Cooling” mode. When the Unit is operating in the “Cooling” function, it does not need the drain pipe installed. Please make sure that the rubber cap is locked on drain hole, when the Unit is running.
  • Page 16 HEATING EFFECT USE OF HEATING FUNCTION If you want to use the heating function, please carry out the following steps: Take off the exhaust duct from the Unit, by rotating it in the direction of the arrow in Fig. 1. Insert the air outlet’s joint part (accessory supplied with the Unit) after removing the matching portion of cold air outlet grille, as shown in Fig.

  • Page 17: Cleaning & Maintenance Of Air Conditioner

    CLEANING & MAINTENANCE OF AIR CONDITIONER MAINTENANCE Before performing any maintenance operation, check that the power plug is disconnected from the wall power socket. Please follow the instructions below: 1. Cleaning the air filters If the filters are dirty, the appliance’s performance decreases.

  • Page 18: Correct Use Of Air Conditioner

    CORRECT USE OF AIR CONDITIONER PLACE FOR USE Because the machine distributes hot air, please don’t place or operate in a narrow place. In case of dangerous leak, don’t work the machine in a humid place. Don’t place the machine in a sunlit corner otherwise the Unit might shut down due to the overheat and the colour of the machine may soon fade out.

  • Page 19: Technical Specifications

    TECHNICAL SPECIFICATIONS TECHNICAL DATA MODEL HMCZ 95 F Power Source 220-240V~50Hz Rated Power (EN 60335) Cooling 1100W Heating 950W Cooling Capacity 2600W Heating Capacity 2600W Moisture Removed 50 liters / day Refrigerant R410A Dimensions (mm) 288 W x 428 D x 625 H European Regulation (CE) N 842/2006: R410A is a kind of fluorinated greenhouse gases covered by Kyoto Protocol.
  • Page 20 Avec le souci d’améliorer sa production, le constructeur se réserve le droit de modifier les spécifications techniques des produits sans préavis. HOKKAIDO srl Via della Salute,14 40132 Bologna Italy Tel.
