Metal
Gate
• gate with no extensions fits:
• gate with 1x 10cm extension fits:
• gate with 2x 10cm extensions fits:
IMPORTANT! READ AND FOLLOW
THESE INSTRUCTIONS CAREFULLY
AND KEEP FOR FUTURE REFERENCE.
This product conforms to EN1930:2011.
73cm - 82cm
83cm - 92cm
93cm - 102cm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for anko Metal Gate
Summary of Contents for anko Metal Gate
- Page 1 Metal Gate • gate with no extensions fits: 73cm - 82cm • gate with 1x 10cm extension fits: 83cm - 92cm • gate with 2x 10cm extensions fits: 93cm - 102cm IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE. This product conforms to EN1930:2011.
- Page 2 G. 2x 10cm Gate Extensions H. 4x Extension Pins If any parts are missing, do not attempt to use your Metal Gate. Please contact Kmart Australia Ltd. to obtain additional or replacement parts. Only use parts supplied by the manufacturer with your Metal Gate.
- Page 3 SAFETY INFORMATION WARNING WARNING - To prevent serious injury or death, securely install gate or enclosure and use according to manufacturer’s instructions. WARNING - Never leave child unattended when using this product. WARNING - Incorrect installation can be dangerous. WARNING - Do not use the safety barrier if any components are damaged or missing. WARNING - The safety barrier must not be fitted across windows.
- Page 4 INSTALLATION Important: Gate must be installed in a structurally sound opening. Ensure mounting surface (wall, door frame, stair posts, ect.) is strong, rigid and has an even surface. If using gate on a stairway, it must be placed on the lowest step at the bottom. 1.
- Page 5 2. When you unpack the gate you may notice a gap at the gate opening, this is normal with pressure mounted gates and the gap will disappear when it is installed correctly. 3. Screw mounting bolts and adjuster screws together and then place into mounting holes in each corner of gate.
- Page 6 Pencil Wall Cup Marks Mounting Bolt Head 4. Place the gate in opening and ensure the bottom rail is completely flat on the floor and the wall cups are directly above each other, mark the position of each mounting cup, stick the cups in position with adhesive pads. For added security, fix each cup to the wall using a small Phillips head screwdriver (not included) and screws provided.
- Page 7 OPERATION To Open Gate 1. Using one hand, place thumb on the button and grip gate with fingers. 2. Slide button and lift gate, then open gate in either direction. When released gate will swing closed. Always check gate is properly closed. NOTE: IF GATE IS OPEN AND EXCESSIVE PRESSURE IS APPLIED, (SUCH AS STANDING OR SWINGING ON GATE) STRUCTURAL DAMAGE MAY OCCUR.
- Page 8 Keycode : 42197096 MADE IN CHINA ©KMART AUSTRALIA LIMITED ANKO, KIDS&CO. & BABY SOLUTIONS® ARE TRADEMARKS OF KMART AUSTRALIA LIMITED. THEY ARE USED IN NEW ZEALAND BY KMART NZ HOLDINGS LIMITED TRADING AS KMART IN NEW ZEALAND. KMART AUSTRALIA - 690 SPRINGVALE RD, MULGRAVE, VIC 3170 AUSTRALIA.
