IMPORTANT: START HERE
1
3
Slide the 5 'S' clamps into
3
the corresponding slot in the
supplied Revolver rail.
4
Align the 'S' clamps
to match the spacing of the
original factory track system
mounting holes.
5 - 'S' clamps for a 5' 6" bed,
6 - 'S' clamps for a 6' 6" bed.
Mount the supplied Revolver rail into
5
the original factory mounting holes
using the supplied Torx screws through
the middle slot of the 'S' clamps.
Align the rail with the
front/cab bulkhead,
per Step 5A,
tighten the screws.
5
A
Position the rail with the silver, slotted bracket all the
way forward, towards the cab, front of the vehicle.
If the truck is equipped with a drop-in bed liner,
remove the foam pad located on the end of
the slotted bracket as shown in FIG B.
Part# 318A0049 Rev. 9-30-15
Install the bulkhead
seal to the top of the
bulkhead at the edge
of the bed opening.
If the truck does
NOT have a drop-in
bed liner, use 3/4"
seal. If the truck does
have a drop in bed
liner, use 1/4" seal.
FIG B
© Laurmark Enterprises, Inc., 2015
SUPPLEMENTAL INSTALL SHEET
Toyota Tundra w/ Track System
Remove the factory installed accessory
2
track system, set aside for reinstallation.
