BAK REALTRUCK REVOLVER X4ts Installation Sheet

E
TOOLS REQUIRED
9/16" wrench or socket
10mm wrench or socket
T40 Torx wrench
TOOLS PROVIDED
1/8" Allen wrench
F
C
If you are installing a new truck bed cover, please start at STEP 7.
Open the rolled cover (E).
1
RealTruck BAK Industries • 1100 N. Glenstone Ave. Suite 140, Spring eld, MO 65802 • 818-365-9000 ©RealTruckGroup, Inc., 2024
D
O
J
K
L
G
H
F
I
B
G H I
REVOLVER X4ts FORD RANGER 2024+
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 818-365-9000 Mon - Fri 8:30 am - 6:00 pm EST
or email support@bakindustries.com
A
C
PARTS INCLUDED
(If installing ts rails to an
M
existing Revolver system)
A 1x Passenger side cover rail
1x Driver side cover rail
B
4x End caps
C
J K
Remove the mounting hardware underneath the
2
slotted bracket on the current passenger side
cover rail and the current driver side cover rail. Keep
the hardware for later reinstallation.
PARTS INCLUDED
(If installing a complete new
N
Revolver X4ts cover system)
1x Bulkhead seal
D
1x Rolled cover
E
6x Clamps
F
6x Clamp bolts
G
6x Clamp washers
H
6x Clamp nuts
I
4x Lock knobs
J
4x Large at washers
K
4x Rubber washers
L
4x Mounting bolts
M
N 2x Strap clamp assemblies
O 4x D-shaped bumpers
M
L
Part#318S0146 Rev. 2-06-2024
