Installation Procedure
Apply Foam Tape
Install Backwall Trim
Apply foam tape to underside of cooktop trim in one continuous piece.
Note:
This step is only required if the countertop does not connect behind
the range (i.e.; when replacing a free-standing range). See "Cabinet
Requirements" on page 8 for more information
Install 2 screws through holes in trim and in range backwall. See Figure 9:
Backwall Trim Strip and Figure 10: Install Backwall Trim Strip
Backwall
Trim Strip
Figure 9: Backwall Trim Strip
Back of Range
Figure 10: Install Backwall Trim Strip
Installation
English 11
