Comtech EF Data LBC-4000 Installation And Operation Manual page 6

L-band up/down converter system
Hide thumbs Also See for LBC-4000:
Table of Contents

Advertisement

To Block Converter
To Modem
Termination
Termination
SLOT
SLOT
B
A
The drawing represents the cabling requirements for redundant operation. BNC to BNC cables should
be 50 Ω BNC-M. Type N to SMA connections is best made with a Type N-M to SMA-F adapter and
SMA-SMA cables.
2
Filename: T_ERRATA
