  • Page 1 White Logo use on black background only 250 lb. Capacity For the Most Up to Date Information and Instructions, TP400 Visit the TranzSporter Web Site at www.tranzsporter.com. 400 lb. Capacity Page 1 of 16 TIE DOWN ENGINEERING • Atlanta, GA 30336 Instructions #08238 www.tiedown.com (404) 344-0000...

  • Page 2: User Responsibilities

    Congratulations on your Purchase of the TranzSporter Lift Hoist. The TranzSporter Lift Hoist was designed to provide safe and continuous operation. Features Include... • Collapsible carriage comes with track cam followers for better tracking and handling. • Aluminum deck and flap for lighter weight and longer life.

  • Page 3: Safety Instructions

    8. Do not climb the TP-Series hoist or use as a personnel ladder. 9. Do not overload - maximum lifting capacity for the TP250 is 250 lbs. with a load capacity of 230 lbs. Maximum lifting capacity for the TP400 is 400 lbs.
  • Page 4 Assembly Instructions for the TP250 Hoist Instructions for the TP400 Hoist skip to page 7 Congratulations on purchasing the TranzSporter TP250 Hoist. Please read the following instructions completely before starting assembly. The TP250 Hoist ships in 4 units: 1) Box - Base Section, Top Cap & Brake Handle 2) Box - Collapsible Carriage &...
  • Page 5 Assembly Instructions for the TP250 Hoist Instructions for the TP400 Hoist skip to page 7 Step 5 Front Lay one track section on a flat floor with the “front” side up. This is determined by the space between the track cross bar and the track Back section edge as shown above.
  • Page 6 Tighten bolt as shown right. Bolt Washer Lock Washer You have completed the assembly of the TP250 Hoist Skip to page 10 for Operation and Placement Instructions. Page 6 of 16 Atlanta, Georgia 30336...
  • Page 7 Assembly Instructions for the TP400 Hoist Congratulations on purchasing the TranzSporter TP400 Hoist. Please read the following instructions completely before starting assembly. The TP400 Hoist ships in 4 units: 1) Box - Base Section, Top Cap & Brake Handle 2) Box - Collapsible Carriage & Plywood Attachments 3) Box - Motor Weldment &...
  • Page 8 Assembly Instructions for the TP400 Hoist Step 4 “Roll”carriage assembly onto the base. At this time lock the base in place using the Safety Pin as shown. Important: Always check for wear or damage to the safety pin cable/ pull ring assembly. Failure to replace damaged safety pin cable assembly may cause damage or personal injury.
  • Page 9 Lock Washer top cap assembly, place the eye end over the bolt, replace the washer/lock washer and tighten the nyloc Cable Eye/End nut as shown right. Cable is looped around carriage pully (404) 344-0000 • www.tranzsporter.com Page 9 of 16...
  • Page 10 Step 11 See “Raising Hoist” instructions (page 12 ) for proper positioning/placement of base at the set at job site. Engine Base Assembly Arm Engine Base Assembly Arm Retaining Rings Step 12 Mount the motor assembly to the base unit; from behind the hoist; the foot pad of the motor base slides under the track base section, while “hanging”...
  • Page 11 Allows use of a left side handle to engage the motor and carriage. It is highly recommended when using with the Solar/Plywood Saddle Carriage. Can be used for both TP250 & TP400 models. Parts included with the Secondary Handle Kit: 1) Handle.

  • Page 12: Gasoline Engine

    Gasoline Engine 1. Handle fuel with care. It is EXTREMELY flammable and explosive under certain conditions. 2. Do not smoke, allow open flames or sparks to be present during the refueling operation. 3. Use only an approved fuel container to transport fuel. 4.
  • Page 13 INCLUDE APPROVED HAND PROTECTION, HEAD PROTECTION AND EYE PROTECTION. To raise the platform on the TP250, face the platform and stand as far as possible from the hoist to operate. Place your foot on the foot control pad to engage the motor to the cable drums V belt, permitting the platform to roll up the track section. When the platform reaches the top, release foot IMMEDIATELY.
  • Page 14 Plywood/Flat Panel Tie Down and Lifting Instructions WARNING WARNING WARNING FAILURE TO READ AND UNDERSTAND THE OPERATING INSTRUCTIONS CAN RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR EVEN DEATH TO USER OR OTHERS • Use the proper tie down equipment - If you are not securing your cargo with the proper safety straps, it could come loose during lifting, resulting in injury or death.
  • Page 15 TRANZSPORTER PRODUCT LINE LIMITED WARRANTY Tie Down Engineering will repair or replace, free of charge, any part, or parts of the TranzSporter lift hoist that are defective in material or workmanship or both. The limited warranty is in effect for 90 days from date of purchase. Return the defective unit to the dealer or contact Tie Down direct at 800-241-1806, x1525.
  • Page 16 28 ft. 28 ft. using with the Solar/Plywood Saddle Carriage. Includes all hardware brackets and handle. Can be used for both TP250 & TP400 models. Part # Hoist Accessories Stand-Off/Stabilizer 48467 TranzSporter Solar/Plywood panel accessory for TP400 Platform Hoist...
