Page 2: User Responsibilities
Power unit - (4 hp. Briggs & Stratton, 4 hp. Honda or High Torque Electric Motor) Self-energizing brake, 4 ft. aluminum base section, 4, 8, and 16 ft. track sections. The TranzSporter Lift Hoist - Series was designed to last. Features include... -
Page 3: Safety Instructions
Do not climb the lift hoist or use as a personnel ladder. Do not overload - maximum lifting capacity for the LH4000 is 400 lbs. with a load capacity of 380 lbs. 10. Keep hands, feet and other body parts as well as clothing away from the track sections and moving or rotating parts of the lift hoist when starting the engine or when operating the hoist. - Page 4 Congratulations on purchasing the TranzSporter LH4000 Hoist. The two boxes contain the five assembled parts plus the owner’s manual, making up the LH4000. Please read the following instructions completely before starting assembly. Refer to the owner’s manual for further information on use and maintenance of the LH200.
- Page 5 Picture 8 Picture 9 6. Remove the plywood/rolled goods brackets from both sides of the lift platform (Picture 10, These are used to hold down the loose platform arms during transporting.) Picture 10 (404) 344-0000 • Fax (404) 349-0401 • www.tranzsporter.com...
- Page 6 7. Lower the platform supports 180 degrees. Lift the middle bar attached to the platform arms and support (shown above). Remove the two quick release pins from the platform base. 8. Position/slide the two support arms into the mounting holes on the cross bar of the platform base.
-
Page 7: Repair Information
Replaces all dated or undated limited warranties dated before May 1, 2001 Tie Down Engineering, Inc. will repair or replace, free of charge, any part, or parts of the TranzSporter lift hoist that are defective in material or workmanship or both. The limited warranty is in effect for 90 days from date of purchase. - Page 8 Raising the Track Section Assembly WARNING: KEEP TRACK SECTIONS CLEAR OF ALL ELECTRICAL WIRES AND EQUIPMENT BE AWARE OF OVERHEAD OBJECTS-NEVER CLIMB HOIST! The hoist assembly is extremely top heavy and must be kept under control at all times. Two alternate methods are suggested for raising the platform hoist to the operating position. PROCEDURE “A”...
-
Page 9: Lowering The Platform
WHICH SHOULD INCLUDE APPROVED HAND PROTECTION, HEAD PROTECTION AND EYE PROTECTION. To raise the platform on LH4000, face the platform and stand as far as possible from the hoist to operate. Place your foot on the foot control brace to engage the motor to drum belt, permitting the platform to roll up the track section. - Page 10 Tie Down Engineering • 5901 Wheaton Drive • Altanta, Georgia 30336...
- Page 12 Tie Down Engineering • 5901 Wheaton Drive • Altanta, Georgia 30336...
- Page 13 Rev. 3/21/2011 (404) 344-0000 • Fax (404) 349-0401 • www.tranzsporter.com...
- Page 14 031711,E1080 Tie Down Engineering • 5901 Wheaton Drive • Altanta, Georgia 30336...
- Page 15 032111,E1080 (404) 344-0000 • Fax (404) 349-0401 • www.tiedown.com...
- Page 16 031711,e640 Tie Down Engineering • 5901 Wheaton Drive • Altanta, Georgia 30336...
