Set up:
All connections of the device should be made before switching on. Only use high-quality cables
that are as short as possible for the connections.
Configuration oft he DMX connector:
Resistance 120 ohm // ¼ w between pin 2 (DMX-) and pin 3 (DMX+) oft he last fixture.
Operating mode DMX:
Connect the DMX input of your device to the DMX output of your DMX controller, your DMX
software or the DMX output of a device already in your DMX line. Always use a DMX cable with a
110 Ohm resistor for this connection. Address the device according to your DMX configuration.
The following table shows the respective DMX modes of the individual devices with the
corresponding values and functions:
2-Channel Mode:
Channel Value
000-010
011-220
1
231-239
240-255
000-015
016-063
064-111
2
112-158
160-207
208-255
Function
Preheat function OFF
Emergency STOP
Cleaning mode
Preheat function ON
Spark Effect OFF
Height 1 meter
Height 2 meter
Height 3 meter
Height 4 meter
Height 5 meter
ENGLISH
Display
E57
CLE
OFF
F1
F2
F3
F4
F5
