OPENING AND CLOSING THE CASE

Raspberry Pi Compute Module installation

To install your own Compute Module in Iono Pi Max Solo, or replace the pre-installed

module, no tools are required once the plastic enclosure has been removed and the circuit

boards assembly is exposed. The Compute Module ﬁts in a standard 200 pin DDR2

SODIMM (JEDEC MO-224 mechanical speciﬁcation) slot.

NOTICE

Static electricity can damage the components in your system. To protect your system's

components from static damage during the installation process, touch any of the unpainted

metal surfaces on your computer's frame or wear an ESD wrist strap before handling

internal components. Either method will safely discharge static electricity that's naturally

present in your body.

When handling the Raspberry Pi Compute Module, be sure to hold it along the side edges

using your thumb and index ﬁnger. Avoid touching the components and pin connectors as

damage can occur.

Align the notches on the Compute Module with the ridges in the DDR2 slot. Insert the

module using ﬁrm and even pressure, and push down on the module until the clips on the

side of the slot snap into place.

How to ﬂash the eMMC

The Compute Module versions 3 and 3+ have an on-board eMMC device connected to the

primary SD card interface.

In order to ﬂash the Compute Module's eMMC memory, an additional board, like the

Compute Module IO Board V3, must be used.

Iono Pi Max has two microSD slots to install ﬂash memory cards.
