AVx: ANALOG VOLTAGE INPUTS
Input voltage range
Input impedance
Total Unadjusted Error (TUE)
Resolution
AIx: ANALOG CURRENT INPUTS
Input current range
Input impedance
Total Unadjusted Error (TUE)
Resolution
ATx: TEMPERATURE SENSORS INPUTS (PT100, PT1000)
Temperature range
Accuracy (not including Pt and cable errors)
Resolution
AOx: ANALOG VOLTAGE OUTPUTS
Output range
Output drive current
Total Error
Resolution
AOx: ANALOG CURRENT OUTPUTS
Output range
Output drive voltage
Total Error
Resolution
DIx: DIGITAL INPUTS
Input voltage range
Input impedance
Voltage threshold
OCx: OPEN COLLECTOR OUTPUTS
Sink current
On resistance
Voltage range
68
0...20 V
> 1 MOhm
±0.06 % of full-scale
24 bits (Max)
-0.5...+24 mA
240 Ohm
±0.08 % of full-scale
24 bits (Max)
-150...+400 °C
± 0.3 °C ± 0.05 % of reading
24 bits (Max)
0...+10 V
15 mA (Max)
±0.5 % of full-scale (Max)
12 bits
0...+20 mA
12 V (Max)
±0.5 % of full-scale (Max)
12 bits
0...40 V
6.9 kOhm
VIH: 4.2 V
VIL: 3.4 V
200 mA (Max)
3 Ohm
0...50 V
