Sliding Gate Opener

RUN1500

Instructions and warnings for the fitter

RUN 1500

Need help?

Do you have a question about the RB400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nice RB400

Page 1 This manual is not for the inverted 2500 model Sliding Gate Opener RUN1500 Instructions and warnings for the fitter RUN 1500...
Page 2 Nota - Il contenuto di questa dichiarazione corrisponde a quanto dichiarato nell’ultima revisione disponibile, prima della stampa di questo manuale, del documento ufﬁciale deposi- tato presso la sede di Nice Spa. Il presente testo è stato riadattato per motivi editoriali. / Note - The contents of this declaration correspond to those of the last revision available...
Page 3 Directive if used in the configurations foreseen in this instruction Visit “www.niceforyou.com” for further information and guidelines for risk manual and in combination with the articles present in the Nice S.p.a. analysis and how to draw up the Technical Documentation. This manu- product catalogue.
Page 4 2) Product description and applications RUN is a range of irreversible electromechanical gearmotors used for is also available at: www.niceforyou.com. RUN is equipped with a the automation of sliding gates. They are equipped with an electron- connector for remote programming units to enable complete and ic control unit and an “SM”...
Page 5 2.2) Typical system Figure 2 shows a typical system for automating a sliding gate using RUN. Key-operated selector switch Rack Receiver FT210B Flashing light with incorporated aerial Photocells Transmitter FT210B 10 “Closed” limitswitch bracket Primary movable edge 11 Primary movable edge (optional) “Open”...
Page 6 3) Installation The installation of RUN must be carried out by qualified personnel in compliance with current legislation, standards and regulations, and the directions provided in this manual. 3.1) Preliminary checks Before proceeding with the installation of RUN: • Ensure that the mounting positions of the various devices are pro- •...
Page 7 In order to prevent the weight of the leaf from affecting 6. Release the gearmotor as shown in “Release and manual move- ment” paragraph in the Chapter “Instructions and Warnings for the gearmotor, it is important that there is a play of 1÷2 users of the RUN gearmotor”.
Page 8 3.4) Installation of the various devices If other devices are required, install them following the directions provided in the corresponding instructions. Check this in paragraph “3.6 Description of electrical connections” and the devices which can be connected to the RUN in Figure 2. 3.5) Electrical connections the diameter of the cables joined by the clamp, and slide the Only carry out electrical connections once the electric-...
Page 9 3.6) Description of the electrical connections The following is a brief description of the electrical connections; for STOP see also Paragraph “7.3.2 STOP Input”. further information please read “7.3 Adding or Removing Devices” STEP-BY-STEP: input for devices which control Step-by-Step paragraph.
Page 10 4.4) Recognizing the length of the leaf After recognizing the devices, L3 and L4 LED’s start flashing; the control unit must recognize the length of the gate. During this stage, the length of the leaf is measured from the closing limit switch to the opening limit switch. This measurement is required to calculate the decel- eration points and the partial opening point.
Page 11 5.1) Testing Each component of the system, e.g. safety edges, photocells, emer- 6. Check the proper operation of all the safety devices, one by one gency stop, etc. requires a specific testing phase. We therefore rec- (photocells, sensitive edges, emergency stop, etc.) and check ommend observing the procedures shown in the relative instruction that the gate performs as it should.
Page 12 7) Additional information Programming, personalisation and how to look for and deal with faults on the ROBUS will be dealt with in this chapter. 7.1) Programming keys The ROBUS control unit feature three keys that can be used to com- mand the control unit both during tests and programming.
Page 13 7.2.2) Level one programming (ON-OFF functions). Level 1 functions are all factory set to “OFF”. However, they can be changed at any time as shown in Table 8. Follow the procedure careful- ly, as there is a maximum time of 10 seconds between pressing one key and another. If a longer period of time lapses, the procedure will fin- ish automatically and memorize the modifications made up to that stage.
Page 14 Led di entrata Parametro Led (livello) Valore Descrizione 0,5 m Adjusts the measurement of the partial 1,5 m opening. Partial opening can be controlled Open Partially with the 2nd radio command or with 2,5 m “CLOSE”, if the “Close” function is present, this becomes “Open partially”.
Page 15 7.2.5) Level one programming example (ON-OFF functions). The sequence to follow in order to change the factory settings of the functions for activating “Automatic Closing” (L1) and “Always close” (L3) have been included as examples. Tabella 11: Level one programming example Example Press the key [Set] and hold it down (approx.
Page 16 7.3.2) STOP input STOP is the input that causes the immediate interruption of the • Two devices with 8,2KΩ constant resistance output can be con- manoeuvre (with a short reverse run). Devices with output featuring nected in parallel; if needed, multiple devices must be connected normally open “NO”...
Page 17 7.3.5) ROBUS in “Slave” mode Properly programming and connecting, ROBUS can function in “Slave” mode; this type of function is used when 2 opposite gates need to be automated with the synchronised movement of the two leaves. In this mode ROBUS works as Master commanding the movement, while the second ROBUS acts as Slave, following the commands transmitted by the Master (all ROBUS are Masters when leaving the factory).
Page 18 Tabella 14: ROBUS Slave programming independent from ROBUS Master Level one functions (ON-OFF functions) Level two functions (adjustable parameters) Stand-by Motor speed Peak Open Gate Indicator Output Slave Mode Motor force Error list On Slave it is possible to connect: •...
Page 19 Control of the number of manoeuvres performed The number of manoeuvres performed as a percentage on the set limit can be verified by means of the “Maintenance warning” function. Fol- low the indications in table 17 for this control. Tabella 17: control of the number of manoeuvres performed Example Press the key [Set] and hold it down (approx.
Page 20 7.6) Troubleshooting The table 19 contains instructions to help you solve malfunctions or errors that may occur during the installation stage or in case of fail- ure. Tabella 19: Troubleshooting Symptoms Recommended checks The radio transmitter does not control the gate Check to see if the transmitter batteries are exhausted, if necessary replace them and the LED on the transmitter does not light up The radio transmitter does not control the gate...
Page 21 7.7.1) Flashing light signalling During the manoeuvre the flashing light FLASH flashes once every second. When something is wrong the flashes are more frequent; the light flashes twice with a second's pause between flashes. Tabella N°21: FLASH flashing light signalling Quick flashes Cause ACTION...
Page 22 The following optional accessories are available for ROBUS: For information on the complete range of accessories, refer to the • PS124 PS124 24 V Buffer battery - 1,2Ah with integrated charger Nice s.p.a. product catalogue. battery. • SMXI or SMXIS 433.92MHz Radio receiver with digital Rolling code.
Page 23 This operation equipped with detection devices that prevent move- has been carefully designed by Nice to make it ment if people or objects are in the way, guaranteeing extremely easy, without any need for tools or physical safe and reliable activation.
Page 24 Nice products. You will get the the control is released the gate will stop. services of a specialist and the most advanced pro-...
Page 25 Notes: The content of the present declaration corresponds to the latest available revision, before the printing of the present manual, of the document registered at the head offices of Nice S.p.a.. The original text of this manual has been readapted for publishing reasons.
Page 26 Headquarter Nice worldwide Nice España Madrid Nice Romania Tel. +34.9.16.16.33.00 Cluj Napoca Nice SpA Nice France Fax +34.9.16.16.30.10 Tel/Fax +40.264.45.31.27 Oderzo TV Italia Buchelay info@es.niceforyou.com info@ro.niceforyou.com Tel. +39.0422.85.38.38 Tel. +33.(0)1.30.33.95.95 Fax +39.0422.85.35.85 Fax +33.(0)1.30.33.95.96 Nice España Barcelona Nice Deutschland info@niceforyou.com info@fr.niceforyou.com...
