Application Guidelines
60Hz
Model HP
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076 10
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076 10
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ042 5.5
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076 10
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076 10
* at EN12900 conditions: To= -10°C(14°F), Tc= 45°C(113°F), RGT= 20°C(68°F), SC= 0K
Only motor code 4, code 5 of MLZ are qualified with R407A/R407F
All performance test data after run-in 72hrs
Motor voltage code 4: 460V/3~/60Hz
MLZ042: Motor voltage code 1: 208-230V/1~/60Hz
10
AB243286444663en-001003
Technical specifications
Nominal Power
cooling capacity * input *
W Btu/h kW
2 3800 12969 1.85
4900 16724 2.40
3 5300 18089 2.63
6400 21843 3.10
4 7900 26962 3.52
5 9200 31399 4.10
6 11200 38225 5.37
7 12200 41638 6.01
14300 48805 6.68
9 16700 56997 7.89
18100 61775 8.64
2 4100 13993 1.98
5300 18089 2.57
3 5700 19454 2.81
6900 23549 3.32
4 8500 29010 3.77
5 9800 33447 4.38
6 12000 40956 5.75
7 13100 44710 6.44
15300 52218 7.15
9 18000 61433 8.45
19400 66212 9.25
2 4100 13900 2.05
5200 17900 2.57
3 5500 18800 2.70
6800 23300 3.34
4 8400 28700 3.94
5 9800 33300 4.55
11400 38900 5.68
6 12000 41000 5.71
7 13300 45200 6.24
15500 53000 7.09
9 18500 63100 8.42
19800 67600 9.26
2 2500 8600 1.32
3300 11200 1.66
3 3500 11900 1.75
4300 14800 2.12
4 5300 17900 2.47
5 6200 21300 2.89
6 7600 25800 3.65
7 8300 28200 3.90
9600 32900 4.40
9 11400 38800 5.15
12000 41100 5.96
Efficiency *
Swept volume
COP EER
W/W Btu/h/W cm /rev cu.in/rev
3
2.04 6.96 33.8 2.06
2.06 7.03 43.5 2.65
2.01 6.86 46.2 2.82
2.07 7.06 57.1 3.48
2.25 7.68 68.8 4.20
2.24 7.65 81.0 4.94
2.09 7.13 98.6 6.02
2.03 6.93 107.5 6.56
2.14 7.30 126.0 7.69
2.12 7.24 148.8 9.08
2.09 7.13 162.4 9.91
2.05 7.00 33.8 2.06
2.06 7.03 43.5 2.65
2.01 6.86 46.2 2.82
2.08 7.10 57.1 3.48
2.26 7.71 68.8 4.20
2.24 7.65 81.0 4.94
2.09 7.13 98.6 6.02
2.04 6.96 107.5 6.56
2.14 7.30 126.0 7.69
2.13 7.27 148.8 9.08
2.09 7.13 162.4 9.91
1.99 6.78 33.8 2.06
2.03 6.94 43.5 2.65
2.05 6.99 46.2 2.82
2.04 6.97 57.1 3.48
2.14 7.29 68.8 4.20
2.15 7.34 81.0 4.94
2.01 6.85 93.1 5.68
2.11 7.18 98.6 6.02
2.13 7.26 107.5 6.56
2.19 7.48 126.0 7.69
2.20 7.50 148.8 9.08
2.14 7.30 162.4 9.91
1.91 6.52 33.8 2.06
1.98 6.75 43.5 2.65
2.00 6.81 46.2 2.82
2.04 6.98 57.1 3.48
2.13 7.28 68.8 4.20
2.16 7.37 81.0 4.94
2.07 7.07 98.6 6.02
2.12 7.24 107.5 6.56
2.19 7.48 126.0 7.69
2.21 7.53 148.8 9.08
2.02 6.90 162.4 9.91
Net weight
Displacement Oil charge
(with oil)
m /h cu.ft/h Litres oz kg
3
7.1 251 1.1 37 31
9.1 321 1.1 37 31
9.7 343 1.1 37 31
12.0 424 1.1 37 31
14.5 512 1.6 54 37
17.0 600 1.6 54 37
20.7 731 1.6 54 37
22.6 798 1.6 54 37
26.5 936 2.7 91 44
31.3 1105 2.7 91 45
34.1 1204 2.7 91 45
7.1 251 1.1 37 31
9.1 321 1.1 37 31
9.70 343 1.1 37 31
12.0 424 1.1 37 31
14.5 512 1.6 54 37
17.0 600 1.6 54 37
20.7 731 1.6 54 37
22.6 798 1.6 54 37
26.5 936 2.7 91 44
31.3 1105 2.7 91 45
34.1 1204 2.7 91 45
7.1 251 1.1 37 31
9.1 321 1.1 37 31
9.70 343 1.1 37 31
12.0 424 1.1 37 31
14.5 512 1.6 54 37
17.0 600 1.6 54 37
19.6 692 1.6 54 37
20.7 731 1.6 54 37
22.6 798 1.6 54 37
26.5 936 2.7 91 44
31.3 1105 2.7 91 45
34.1 1204 2.7 91 45
7.1 251 1.1 37 31
9.1 321 1.1 37 31
9.70 343 1.1 37 31
12.0 424 1.1 37 31
14.5 512 1.6 54 37
17.0 600 1.6 54 37
20.7 731 1.6 54 37
22.6 798 1.6 54 37
26.5 936 2.7 91 44
31.3 1105 2.7 91 45
34.1 1204 2.7 91 45
